Huawei Quidway R2600 Series User Manual

Installation Manual
Quidway R2600/3600 Series Modular Routers
Chapter 8
Function Modules
8-62
z V.24 DCE cable
z
V.24 DTE cable
One end of the cables is connected to the router side via the DB-200 connector, and the
connection of the other end of the cables is varied with the network side to which it is
connected.
Caution:
The above four cables are optional. Make sure that you have selected the necessary cables when
purchasing 8LSA module.
I. 8LSA interface cable pinouts (V.24 DCE)
Figure 8-60 8LSA interface cable (V.24 DCE)
