Installation Manual
Quidway R2600/3600 Series Modular Routers
Chapter 4
Installation
4-7
Table 4-2 Console cable pinouts
RJ-45 Signal Direction DB-25 DB-9
1 CTS ---> 5 8
2 DSR ---> 6 6
3 RXD ---> 3 2
4 GND --- 7 5
5 GND --- 7 5
6 TXD <--- 2 3
7 DTR <--- 20 4
8 RTS <--- 4 7
IV. Connecting console cable
While configuring the router at the configuration terminal, connect the console cable in
the following steps:
Step 1: Plug the console cable’s DB-9 (or DB-25) connector to the serial interface in the
PC or the terminal where the router is to be configured.
Step 2: Connect the RJ-45 connector of the console cable to the console of the router.
Caution:
When connecting the cables, check the ID on the interfaces to avoid wrong connection.
For the connection of the console cable, see Figure 5-1 in Chapter 5 Startup and Configuration.
4.4.2 Connecting AUX Port
I. Introduction to AUX
R2600/3600 series provide an AUX in compliance with the EIA/TIA-232 asynchronous
serial standard. Through this interface, you can implement the remote configuration
and maintenance of the router.
II. Attributes of AUX
Table 4-3 Attributes of AUX
Attributes Description
Connector RJ-45
Interface standard Async EIA/TIA-232
Baud rate 300bps to 115.2Kbps
Services supported Dialup via Modem
