Installation Manual
Quidway R2600/3600 Series Modular Routers
Chapter 8
Function Modules
8-32
Serial No DB-25 network end DB-9 network end Signal 200 PIN SCSI router end
5 8 CTS 159
6 6 DSR 124
3 2 RxD 158
7 5 GND 157
8 1 CD 125
2 3 TxD 123
20 4 DTR 156
14
4 7 RTS 122
5 8 CTS 163
6 6 DSR 128
3 2 RxD 162
7 5 GND 161
8 1 CD 129
2 3 TxD 127
20 4 DTR 160
15
4 7 RTS 126
5 8 CTS 167
6 6 DSR 132
3 2 RxD 166
7 5 GND 165
8 1 CD 133
2 3 TxD 131
20 4 DTR 164
16
4 7 RTS 130
Note:
The pins not referenced in the above table are not connected.
8.7.6 Connecting Interface Cable
Step 1: Connect the 8AS and 16AS interface cable:
z For the 8-port asynchronous serial interface cable, connect its 68-pin male
connector to the 68-pin female interface. The eight DB-25 connectors or DB-9
connectors of the cable can be respectively connected to different network ports.
z For the 16-port asynchronous serial interface cable, connect its 200-pin male
connector to the 200-pin female interface. The sixteen DB-25 connectors or DB-
9 connector of the cable can be respectively connected to different network ports.
Step 2: Screw up the knob to fix the 8AS/16AS interface cable to the DB-68 interface
(8AS) or DB-200 interface (16AS).
Step 3: Power on the system and check the status of READY indicator on the front
panel of the router. It is on when the module has completed self-check and works
normally. It is off when the module fails to pass the self-check. In this case, please
contact the local agent of Huawei.
Step 4: Power on the system and check the states of the indicators on the front panels
of 8AS and 16AS:
To Next Page
