Installation Manual
Quidway R2600/3600 Series Modular Routers
Chapter 8
Function Modules
8-3
Slot 7 Slot 5 Slot 6 Slot 4
Slot 3 Slot 1 Slot 2 Slot 0
Figure 8-6 Arrangement of the R3680/3680E slots
8.3 Function Modules Installation
Before installing the function modules, please carefully read Chapter 3 Installation
Preparations.
Caution:
The reed on the lever of function module has special effect of the electromagnetic shield on the whole
router. Please ensure the integrity of the reed when uninstalling or replacing function modules and never
remove the reed.
Warning:
Before performing any of the following operations, make sure you turn off the power that the router is
connected; otherwise, electric shock is likely to occur.
I. Installation tools
z
Flathead screwdriver
z
ESD-preventive wrist strap
II. Installing the interface unit of function modules
The installation steps are as follows:
