Installation Manual
Quidway R2600/3600 Series Modular Routers
Chapter 8
Function Modules
8-2
AUX
CONSOLE
SLOT1
SLOT0
WAN0WAN1
Figure 8-2 Arrangement of the R2621 slots
Slot 1
Slot 2
Slot 0
Figure 8-3 Arrangement of the R2630/2630E slots
Slot 2 Slot 1
Slot 0
Figure 8-4 Arrangement of the R2631/2631E slots
Slot 3 Slot 2
Slot 1 Slot 0
Figure 8-5 Arrangement of the R3640/3640E slots
