Data plan
Table 11-26 Data plan
Item Data
DBA profile Profile name: fttb_dba
Profile type: type3
Assured bandwidth: 8 Mbit/s
Maximum bandwidth: 20 Mbit/s
Line profile Profile name: fttb(c)
Profile ID: 10
T-CONT ID: 4
GEM port ID for management service: 11
GEM port ID for Internet access service: 12
GEM port ID for VoIP service: 13
Network topology data PON port: 0/2/1
ONT ID: 1
Procedure
Step 1 Configure GPON ONU profiles.
1. Configure a DBA profile.
huawei(config)#dba-profile add profile-name fttb_dba type3 assure 8192 max
20480
2. Configure an ONU line profile.
a. Add GPON ONU line profile 10 fttb(c).
huawei(config)#ont-lineprofile gpon profile-id 10 profile-name fttb(c)
NOTE
The ID of the line profile to be created must not exist in the system and the line profile must be
created according to the data plan. In this example, line profile 10 is used.
b. In the line profile mode, bind T-CONT 4 to DBA profile fttb_dba.
huawei(config-gpon-lineprofile-10)#tcont 4 dba-profile-name fttb_dba
c. In the line profile mode, bind the GEM port to the T-CONT.
l Add GEM port 11 to carry management service flows.
l Add GEM port 12 to carry Internet access service flows.
l Add GEM port 13 to carry VoIP service flows.
Bind GEM ports 11, 12, and 13 to T-CONT 4. In configuring, QoS policies for various
service flows also need to be configured. For details about QoS data plan, see 11.2.2
Principle of QoS Data Plan.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
11 FTTB and FTTC Solution Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
979
