EMU ID: 2
----------------------------------------------------------------------------
EMU name : H801VESC
EMU type : H801VESC
Used or not : Used
EMU state : Normal
Frame ID : 0
Subnode : 25
----------------------------------------------------------------------------
huawei(config)#interface emu 2
huawei(config-if-h801vesc-2)#vesc digital 0 available-level low-level name
Temperature
huawei(config-if-h801vesc-2)#vesc digital 1 available-level low-level name Door
huawei(config-if-h801vesc-2)#vesc digital 2 available-level low-level name
Arrester
huawei(config-if-h801vesc-2)#vesc digital 3 available-level low-level name Fan
huawei(config-if-h801vesc-2)#display vesc environment info
EMU ID: 2 VESC environment state
---------------------------Digital environment info-------------------------
ID Name State Value |ID Name State Value
0 Temperature Normal 0 |1 Door Alarm 1
2 Arrester Normal 0 |3 Fan Normal 0
4 - Normal 1 |5 - Normal 1
6 - Normal 1
----------------------------------------------------------------------------
huawei(config-if-h801vesc-2)#quit
huawei(config)#save
1.3.16.4 Configuring the Environment Monitoring Parameters of the EPS30-4815AF
This topic describes how to configure the environment monitoring parameters of the
EPS30-4815AF through the CLI.
Mapping Between Monitoring Parameters and Device Ports
Table 1-25 describes the mapping between the monitoring parameters displayed on the sensor
transfer box.
Table 1-25 Mapping between the monitoring parameters displayed on the host and the ports on
the sensor transfer box
Monitoring Parameter Displayed on the
Host
Device Port
Temperature TEM-HU
Humidity TEM-HU
Digital 0 JTD1
Digital 1 JTD2
Digital 2 JTD3
Digital 3 JTD4
Digital 4 JTD5
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 1 Commissioning
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
89
