10.6.1.9 Configuring the SIP-based Voice Service (on a Web Page)
The OLT is connected to the remote ONU through a GPON port to provide users with the SIP-
based high-quality and low-cost VoIP service.
Prerequisites
l The SIP interface data and POTS user data corresponding to the MG interface have been
configured on the SIP server.
l The connection between the OLT and the SIP server is set up. The OLT can ping the IP
address of the SIP server successfully.
l The ONU has been added to the OLT. For details, see 10.6.1.3 Adding an ONU to an
OLT.
l Different voice services require different ONU software versions. Before the configuration,
ensure that the current ONU software version supports SIP. For details, see relevant ONU
manuals.
Data Plan
Item Data
ONU line profile Profile name: ftth
T-CONT ID: 4
GEM port ID: 12
VLAN plan Single VLAN tag:
l VLAN ID: 300
l VLAN type: smart
l VLAN attribute: common
l CVLAN=SVLAN
VLAN translation policy:
l ONU: provides the VoIP service and uses the same
SVLAN.
Voice parameter IP address of the SIP server: 200.200.200.200/24
Port ID of the SIP server: 5060
Home domain name: huawei.com
User phone number 1: 77730010
User phone number 2: 77730020
Procedure
l Configure the OLT.
1. Configure a traffic profile.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
10 FTTD Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
770
