huawei(config)#dhcp domain stb //Create Option 60 domain name stb for STBs.
huawei(config-dhcp-domain-stb)#dhcp-server 1 vlan 100 //Bind DHCP server group
1 to the DHCP domain where the STBs locate. After the configuration, the STBs in
the DHCP domain are corresponded to DHCP server group 1.
huawei(config-dhcp-domain-stb)#quit
Step 6 Set IP addresses of the gateways for the DHCP domain.
huawei(config)#interface vlanif 100
huawei(config-if-vlanif100)#dhcp domain default gateway 10.100.187.1
10.100.8.1 //Set the IP address of the gateway for the PC domain to 10.100.187.1
for paid PCs and to 10.100.8.1 for overdue PCs.
huawei(config-if-vlanif100)#dhcp domain docsis gateway 10.10.224.1 //Set the IP
address of the gateway for the CM domain to 10.10.224.1.
huawei(config-if-vlanif100)#dhcp domain pktc gateway 10.100.224.1 //Set the IP
address of the gateway for the MTA domain to 10.100.224.1.
huawei(config-if-vlanif100)#dhcp domain stb gateway 10.200.160.1 //Set the IP
address of the gateway for the STB domain to 10.200.160.1.
huawei(config-if-vlanif100)#quit
----End
16.3.1.4 Configuring a Route
This section describes how to implement network communication by configuring a route in
Layer 3 networking with an optical line terminal (OLT). Through the route, packets are
forwarded at Layer 3 between the OLT and its upper-layer devices or servers.
Prerequisites
The upper-layer router has been configured.
Data Plan
Table 16-7 Data plan for the Layer 3 interfaces on the network side
Item IP Address
Layer 3 interfaces on the
OLT network side
Forwarding Dynamic Host Configuration Protocol (DHCP) and
broadband packets:
l VLAN ID: 2004
l Port number: 0/4/0
l IP address: 11.11.11.10/24
Forwarding cable modem (CM) management, VoD, COPS, and
multicast packets:
l VLAN ID: 2005
l Port number: 0/5/0
l IP address: 11.11.12.10/24
Layer 3 interfaces
connecting the router to
the OLT
l Forwarding DHCP and broadband packets: 11.11.11.11
l Forwarding CM management, VoD, COPS, and multicast
packets: 11.11.12.11
l COPS gateway IP address: 192.168.60.1
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
16 OptiCable D-CMTS Configuration (MA5633 Working as
a Standalone NE)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1685
