1.3.5.1 Login Through the Local Serial Port
When you need to maintain and manage the MA5600T/MA5603T/MA5608T locally, you can
log in to the system through the local serial port.
Prerequisites
l A maintenance terminal (generally a laptop configured with a HyperTerminal application)
must be available.
l An RS-232 serial port cable (one end with an RJ45 connector and the other end with a DB-9
or DB-25 female connector) must be available.
Networking
Figure 1-10 shows the networking for logging in to the MA5600T/MA5603T/MA5608T
through the local serial port.
Figure 1-10 Logging in to the MA5600T/MA5603T/MA5608T through the local serial port
PC
Serial port
RS-232 cable
Access node
Flowchart
Figure 1-11 shows the flowchart for logging in to the system through the local serial port.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 1 Commissioning
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
21
