out of port 0/5/0 are untagged.
huawei(config-if-eth-0/5)#quit
3. Create VLAN Layer 3 interfaces.
a. Create the Layer 3 interface of VLAN 2004, through which DHCP and broadband
packets are forwarded.
huawei(config)#interface vlanif 2004
huawei(config-if-vlanif2004)#ipv6 address 2001:0db8:0007::12/64
huawei(config-if-vlanif2004)#quit
b. Create the Layer 3 interface of VLAN 2005, through which CM management packets,
multicast packets, and VoD packets are forwarded.
huawei(config)#interface vlanif 2005
huawei(config-if-vlanif2005)#ipv6 address 2001:0db8:0008::13/64
huawei(config-if-vlanif2005)#quit
Step 2 Configure static routes for the communication between the OLT and its upper-layer devices.
huawei(config)#ipv6 route-static ::/0 2001:0db8:0007::6/64 //Broadband packets
are forwarded through the Layer 3 interface of VLAN 2004.
huawei(config)#ipv6 route-static 2001:0db8:0011::/64 2001:0db8:0008::7/64 //CM
management packets are forwarded through the Layer 3 interface of VLAN 2005.
huawei(config)#ipv6 route-static 2001:0db8:0006::/64 2001:0db8:0007::6/64 //
DHCP packets are forwarded through the Layer 3 interface of VLAN 2004.
NOTE
Configure static routes on the router connected to the OLT. In addition, add the static routes to dynamic ones.
----End
Result
The OLT can communicate with its upper-layer devices. To check network connectivity between
two devices, run the ping ipv6 and tracert ipv6 commands.
The configured static routes can be queried in an IPv6 routing table by running the display ipv6
routing-table command.
15.3.1.7 Adding a Remote Extended Frame to an OLT
An MA5633 that works as a remote extended frame connects to a port on a cascading board of
an optical line terminal (OLT). You can configure the remote extended frame only after adding
it to the OLT.
Prerequisites
The MA5633 management policy is set to extend-frame. To do so, run the sysman centralized-
mgmt primary command.
Context
A GPON remote extended frame is added to an OLT in the following two steps: Add the MA5633
to the OLT as a GPON optical network unit (ONU). Then add the MA5633 to the OLT as a
GPON remote extended frame.
You can use either of the methods listed in the following table to add a remote extended frame
to an OLT based on site requirements.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
15 OptiCable D-CMTS Configuration (MA5633 Working as
a Remote Extended Frame)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1549
