domain of CMs.
huawei(config-if-vlanif100)#quit
----End
15.4.1.6 Configuring a Route (IPv6)
This section describes how to implement network communication by configuring a route in
Layer 3 networking with an OLT. Through the route, the OLT can forward packets at Layer 3
between the OLT and its upper-layer devices or servers.
Prerequisites
The upper-layer router of the OLT has been configured.
Data Plan
Table 15-33 DHCP data plan
Configuration Item Data
Terminal-side of CM
l network segment of CM: 2001:0db8:0001::/64
l network segment of PCs with fees paid: 2001:0db8:0003::/64
l network segment of overdue PCs: 2001:0db8:0004::/64
User-side of OLT
l IP address of the gateway for the DHCP domain of CMs:
2001:0db8:0001::1/64; domain name: docsis
l IP address of the gateway for the DHCP domain of PCs with
fees paid: 2001:0db8:0003::3/64; domain name: default
l IP address of the gateway for the DHCP domain of overdue
PCs: 2001:0db8:0004::4/64; domain name: default
Network-side of OLT Forwarding DHCP and broadband packets:
l VLAN ID: 2004
l Port number: 0/4/0
l IP address: 2001:0db8:0007::12/64
Forwarding CM management packets, multicast packets, and
VoD packets:
l VLAN ID: 2005
l Port number: 0/5/0
l IP address: 2001:0db8:0008::13/64
Router
l IP address of the Layer 3 interface for forwarding DHCP and
broadband packets: 2001:0db8:0007::6/64
l IP address of the Layer 3 interface for forwarding CM
management packets: 2001:0db8:0008::7/64
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
15 OptiCable D-CMTS Configuration (MA5633 Working as
a Remote Extended Frame)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1603
