F/S/P : 0/1/0
ONT-ID : 1
Control flag : active //Indicates that the ONU is
activated.
Run state : online //Indicates that the ONU goes online
successfully.
Config state : normal //Indicates that the configuration state of the
ONU is normal.
Match state : match //Indicates that the capability profile bound to
the ONU is consistent with the actual capability of the ONU.
...//The rest of the response information is omitted.
When Config state is failed, Run state is offline, or Match state is mismatch:
l If Control flag is deactive, run the ont active command in GPON mode to activate the ONU.
l If Run state is offline, a physical line may be broken or the optical module may be damaged.
Check the line and the optical module.
l If Config state is failed, the configured ONU capability exceeds the actual ONU capability.
In this case, run the display ont failed-configuration command in the diagnose mode to
check the failed configuration item and the failure cause. Then, rectify the fault accordingly.
----End
10.6.2.4 Configuring a VDSL2 User Port
Services can be transmitted only after a VDSL2 port is activated on an optical network unit
(ONU). This section describes how to activate a VDSL2 port and bind a VSDL2 line profile to
the port.
Prerequisites
l An ONU has been added to the optical line terminal (OLT). For details, see 10.6.1.3 Adding
an ONU to an OLT.
l Run the display xdsl mode command to check whether the VDSL2 mode is the desired
mode. The default mode is TR129. If the current mode is not the desired one, run the switch
vdsl mode to command in diagnose mode to switch the mode to the desired mode.
NOTE
l A fiber to the door (FTTD) network supports only the TR129 and TR165 modes.
l G.INP takes effect preferentially if both G.INP and SRA are enabled.
Typical VDSL2 Line Parameter Configurations
Key parameters to be configured do not vary with the VDSL2 mode but belong to different
profiles. Hence, commands for configuring the key parameters vary with the VDSL2 mode.
Table 10-6 lists the typical configurations for key parameters of a VDSL2 line (26 AWG, 0.4
mm twisted pair). Information provided in this table is for reference only. Usually, take the
default values for the other parameters.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
10 FTTD Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
792
