Item Procedure Remarks
ONU Configure the
Internet access
service.
Configure the
ADSL2+
Internet access
service on the
ONU.
NOTE
Different ONUs have different ports, including
ADSL2+, VDSL2, and VDSL2 vectoring ports,
for the Internet access. Select an appropriate
configuration method according to the port type.
Configure the
VDSL2
Internet access
service on the
ONU.
(Optional)
Configure
vectoring on
the ONU
Configure the
VoIP service.
Configure the
H.248 -based
VoIP service on
the ONU.
NOTE
The H.248 and SIP protocols are mutually
exclusive for the VoIP service. Only one of them
is configured at a time.
Configure the
SIP-based
VoIP service on
the ONU.
OLT
ONU
Configure the link aggregation,
congestion control, and security
policy.
The global configuration of upstream link
aggregation and queue scheduling based on
priorities ensures service reliability. The
global configuration of security policies
ensures service security.
ONU Verify the service. The ONU provides remote verification
methods including PPPoE dialup emulation
and call emulation for configuration and
commissioning engineers to verify services
remotely after service configuration,
avoiding a second on-site operation.
11.3.2.3 Adding an ONU to an OLT
Services can be configured for an ONU only after the ONU is successfully added to an OLT.
Context
l When an ONU is added, corresponding profiles need to be bound to the ONU, including
the dynamic bandwidth allocation (DBA) profile, line profile, and alarm profile. For details
about functions and configuration methods for these profiles, see Table 11-8.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
11 FTTB and FTTC Solution Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
884
