Huawei SmartAX MA5600T User Manual

Table 11-8 Introduction to ONU profiles
Profile
Type
Function Command
DBA
profile
A DBA profile describes GPON
traffic parameters. A T-CONT
is bound to a DBA profile for
dynamic bandwidth allocation,
improving upstream bandwidth
utilization.
Query a DBA profile. display dba-
profile
Add a DBA profile. dba-profile add
Line
profile
A line profile describes binding
between the T-CONT and the
DBA profile, the QoS mode of
the service flow, and mapping
between the GEM port and the
ONU-side service.
Query a line profile. display ont-
lineprofile
Add a line profile. ont-lineprofile add
Alarm
profile
An alarm profile contains a
series of alarm threshold
parameters that are used for
performance measurement and
monitoring of the activated
ONT lines.
Query an alarm profile. display gpon
alarm-profile
Add an alarm profile. gpon alarm-
profile add
l An ONU can be added in two modes. Select either mode as required.
Mode Usage Scenario Command
Add an
ONU
offline.
The ONU password or serial
number (SN) is obtained.
Run the ont add command to add an
ONU.
Online
confirm
an ONU.
Both the ONU password and SN
are not obtained.
In the GPON mode, run the port ont-
auto-find command to enable the ONU
auto-discovery function of a GPON port
and then run the ont confirm command
to add an ONU.
Data plan
Table 11-9 Data plan
Item Data
DBA profile Profile name: fttb_dba
Profile type: type3
Assured bandwidth: 8 Mbit/s
Maximum bandwidth: 20 Mbit/s
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 11 FTTB and FTTC Solution Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
885
