1.2.3 Preparing Tools
This topic describes how to prepare the tools required before the commissioning. This facilitates
the subsequent commissioning.
Table 1-3 lists the tools to be prepared for the commissioning.
Table 1-3 Tool checklist
SN Item Description Remarks
1 Cables One RS-232 serial port cable (One end
with an RJ-45 connector used to
connect to the board and the other end
with a DB-9 or DB-25 female
connector used to connect to the
maintenance terminal)
Used to connect the
maintenance terminal to the
MA5600T/MA5603T/
MA5608T for maintenance
through the serial port.
One crossover cable Used to connect the
maintenance terminal to the
MA5600T/MA5603T/
MA5608T for maintenance
through telnet.
Some optical fibers and patch cords
with different connectors
Used for the upstream
transmission and optical
power test.
2 Maintena
nce
terminal
One maintenance terminal configured
with a HyperTerminal application,
such as a laptop
Used to log in to the
MA5600T/MA5603T/
MA5608T to commission the
MA5600T/MA5603T/
MA5608T.
3 Auxiliary
device
and meter
One optical power meter Used to test the mean
launched power and the input
optical power of an optical
port.
One optical attenuator Used to attenuate the input
optical signal. It is used to
protect the optical port from
being damaged by intense
optical signals during the
device commissioning.
One multimeter Used to measure the voltage,
resistance and current
intensity during the power
commissioning.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 1 Commissioning
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
5
