management packets are forwarded through the Layer 3 interface of VLAN 2005.
huawei(config)#ipv6 route-static 2001:0db8:0006::/64 2001:0db8:0007::6/64 //
DHCP packets are forwarded through the Layer 3 interface of VLAN 2004.
NOTE
Configure static routes on the router connected to the OLT. In addition, add the static routes to dynamic ones.
----End
Result
The OLT can communicate with its upper-layer devices. To check network connectivity between
two devices, run the ping ipv6 and tracert ipv6 commands.
The configured static routes can be queried in an IPv6 routing table by running the display ipv6
routing-table command.
15.4.1.7 Adding a Remote Extended Frame to an OLT
A distributed cable modem termination system (D-CMTS) that works as a GE remote extended
frame connects to a port on a GE cascading board of an optical line terminal (OLT). You can
configure the remote extended frame only after adding it to the OLT.
Prerequisites
The D-CMTS management policy is set to extend-frame. To do so, run the sysman centralized-
mgmt primary command.
Context
You can use either of the methods listed in the following table to add a remote extended frame
to an OLT based on site requirements.
Table 15-34 Methods of adding a remote extended frame to an OLT
Method Usage Scenario Remarks
Add a remote
extended frame
in offline mode.
The remote extended frames
must be deployed one by one.
This method facilitates remote
extended frame management.
The remote extended frame ID has
been planned.
Add an
automatically
discovered
remote extended
frame.
A great number of remote
extended frames need to be
deployed. This method reduces
manual configurations.
The remote extended frame ID does
not need to be planned.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
15 OptiCable D-CMTS Configuration (MA5633 Working as
a Remote Extended Frame)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1605
