Data Plan
Table 15-35 Data plan
Item Data
GE cascading
board
Board: H801ETHB
Port ID: 0/3/1
Remote extended frame ID: 1
NOTE
The OLT uses the MA5603T as an example. The configuration method is the
same for other OLTs. The only difference lies in slot IDs.
Procedure
l Add a remote extended frame in offline mode.
huawei(config)#interface eth 0/3
huawei(config-if-eth-0/3)#network-role extend
This operation will reset the board. Are you sure to continue ? (y/n)[n]:y
huawei(config-if-eth-0/3)#quit
huawei(config)#frame add 1 MA5633 extending-port 0/3/1
l Add an automatically discovered remote extended frame.
The OLT supports the adding of an automatically discovered GE remote extended frame.
This function does not require manual confirmation, thereby simplifying the remote
extended frame registration and adding flow.
huawei(config)#interface eth 0/3
huawei(config-if-eth-0/3)#network-role extend
This operation will reset the board. Are you sure to continue ? (y/n)[n]:y
huawei(config-if-eth-0/3)#quit
----End
Result
The remote extended frame is online.
After adding the remote extended frame, run the display frame info command to query the
remote extended frame status. Ensure that Online state is online and State is normal.
huawei(config)#display frame info 1
--------------------------------------------------------------------------
Type: MA5633
State: Normal
Desc: MA5633_1_extending_0/3/1
Hardware: MA5633
Extend type: ETH
Extending port: 0 /3 /1 //The cascading port on the OLT is 0/3/1.
Extended port: 1 /0 /0 //The ID of the remote extended frame is 1 and the uplink
port on the remote extended frame is 0/0/0.
Online state: Online
MAC address: 60DE-447D-8711
--------------------------------------------------------------------------
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
15 OptiCable D-CMTS Configuration (MA5633 Working as
a Remote Extended Frame)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1606
