Table 1-65 DBA profile 8

Profile

Index

Profile Name Default

8 Profile-name dba-profile_8

Profile-ID 8

Type 2

Bandwidth compensation No

Fix bandwidth(kbps) 0

Assure bandwidth(kbps) 102400

Maximum bandwidth(kbps) 0

Table 1-66 DBA profile 9

Profile Name Default

Profile-name dba-profile_9

Profile-ID 9

Type 3

Bandwidth compensation No

Fix bandwidth(kbps) 0

Assure bandwidth(kbps) 32768

Maximum bandwidth(kbps) 65536

1.6.3.6 Default settings of the GPON ONT line profile

The following table lists the default settings of the GPON ONT line profile on the MA5600T/

MA5603T/MA5608T.

Table 1-67 GPON ONT line profile

Parameter Name Default

FEC upstream switch Disable

Qos mode PQ

Mapping mode VLAN

<T-CONT 0> DBA Profile-ID:1

SmartAX MA5600T/MA5603T/MA5608T Multi-service

Access Module

Commissioning and Configuration Guide

1 Commissioning

Issue 01 (2014-04-30) Huawei Proprietary and Confidential

213

About this Document3
- Intended Audience3
- Table of Contents6
1 Commissioning26
- Commissioning Introduction27
- Commissioning Definition27
- Commissioning Procedure27
- Commissioning Preparations28
- Checking Hardware28
- Preparing Software29
- Preparing Tools30
- Planning Data31
- Stand-Alone Commissioning32
- Checking the Settings of DIP Switches32
- Checking the Settings of DIP Switches on the H801ESC Board32
- Checking the Settings of DIP Switches on the Fan Monitoring Board36
- Powering on the Device41
- Commissioning the Power Supply System42
- Checking the Power Supply of the DC PDU42
- Checking the Power Supply of the Power Board42
- Configuring the Maintenance Terminal43
- Logging in to the System45
- Login through the Local Serial Port46
- Login through Telnet (Outband Management)51
- Login through Telnet (Inband Management)57
- Login through SSH (Outband Management)63
- Login through SSH (Inband Management)74
- Checking the Software State86
- Loading a Configuration Script88
- Changing the System Name89
- Configuring the System Time90
- Configuring a System User92
- Adding a System User92
- Modifying the System User Attributes94
- Configuring a Board96
- Adding a Board Offline97
- Confirming a Board98
- Checking the Board Status99
- Checking the Status of the Upstream Port100
- Checking the Status of the Service Port100
- Enabling the ONT Automatic Discovery Function101
- Testing the Optical Power of an Optical Port101
- Measuring the Transmit Optical Power of an OLT PON Port101
- Measuring the Receive Optical Power of an OLT PON Port103
- Measuring the Transmit Optical Power of an ONU PON Port104
- Measuring the Receive Optical Power of an ONU PON Port106
- Commissioning the EMU108
- Environment Monitoring Application108
- Commissioning the EMU_ESC109
- Configuring H801VESC Environment Monitoring Parameters112
- Configuring the Environment Monitoring Parameters of the EPS30-4815AF114
- Configuring the Environment Monitoring Parameters of the EPS75-4815AF120
- Configuring the Environment Monitoring Parameters of the GEPS4845128
- Configuring the Environment Monitoring Parameters of the ETP4830134
- Configuring the Environment Monitoring Parameters of the ETP4890140
- Configuring the Power3000 Environment Monitoring Mode145
- Commissioning the EMU_TCU148
- Commissioning the EMU_FAN150
- Saving and Backing up Data152
- Manually Saving and Backing up Data152
- Configuring the Auto-Save and Auto-Backup Functions156
- Interconnection Commissioning160
- Commissioning the Interconnection with the NMS161
- Commissioning Outband Network Management (SNMP V1 and V2)161
- Commissioning Outband Management (SNMP V3)168
- Commissioning Inband Management (SNMP V1 and V2)174
- Commissioning Inband Network Management (SNMP V3)181
- Commissioning the Interconnection with the Router187
- Commissioning the Interconnection with the BRAS188
- Interconnection Commissioning of the MG Interface190
- Commissioning the Interconnection with the MG Interface(H.248)190
- Commissioning the Interconnection with the MG Interface (MGCP)193
- Commissioning the Interconnection with the SIP Interface196
- Commissioning the Management Channel between the OLT and the GPON MDU199
- Commissioning the Management Channel between the OLT and the GPON ONT204
- Commissioning the Management Channel to the Xdsl CPE207
- Maintenance and Management Commissioning210
- Configuring the System Energy-Saving Function210
- Checking Alarms and Events212
- Verifying the Alarm and Event Function212
- Querying Alarms and Events212
- Checking the Log215
- Checking the System Switchover216
- Supplementary Information218
- Script Making218
- Configuring the File Transfer Mode219
- Configuring the FTP Transfer Mode220
- Configuring the SFTP Transfer Mode221
- Configuring Xmodem File Transfer Mode222
- Configuring the TFTP Transfer Mode224
- Software Package Settings227
- Factory Default of the Xdsl Line Profile227
- Factory Defaults of the Xdsl Alarm Profile232
- Default Settings of the System Parameters234
- Default Settings of the Overseas Parameters235
- Factory Defaults of a DBA Profile235
- Default Settings of the GPON ONT Line Profile238
- Default Settings of the GPON ONT Service Profile239
- Factory Defaults of a GPON ONT Alarm Profile239
- Default Settings of the Environment Monitoring Units241
2 Basic Configurations243
- Configuring Alarms244
- Adding Port Description247
- Configuring the Attributes of an Upstream Ethernet Port248
- Configuring AAA251
- Configuring the Local AAA252
- Configuring the Remote AAA (RADIUS Protocol)253
- Configuration Example of the RADIUS Authentication and Accounting262
- Configuring the Remote AAA (HWTACACS Protocol)265
- Configuration Example of the HWTACACS Authentication (802.1X Access User)269
- Configuration Example of HWTACACS Authentication (Management User)272
- Configuring DOCSIS Event Reporting275
3 Configuring the DSLAM Services277
- Example: Configuring the Xdsl Internet Access Service278
- Example: Configuring the Xdsl Internet Access Service through Pppoe Dialup278
- Example: Configuring the Xdsl Ipoe Internet Access Service285
- Example: Configuring the Xdsl Pppoa Internet Access Service292
- Example: Configuring the Xdsl Ipoa Internet Access Service298
- Example: Configuring the Internet Access Service in the Xdsl 802.1X Mode305
- Configuration Example of Changing ADSL Internet Access Service to VDSL Internet Access Service (for the VDSL2 Board)313
- Example: Configuring the Xdsl Multicast Service317
- Configuration Example of the Multicast Video Service (Static Program Configuration)317
- Configuration Example of the Multicast Video Service (Dynamic Program Generation)322
- Example: Configuring the Voip Service326
- Example: Configuring the Voip Service (H.248-Based)326
- Example: Configuring the Voip Service (MGCP-Based)334
- Example: Configuring the Voip PSTN Service (SIP)341
- Example: Configuring the Voip Service (H.248-Based and SIP-Based)348
- Example: Configuring the P2P ISDN BRA Service353
- Example: Configuring the P2P ISDN BRA Service (Based on the SIP Protocol)357
- Example: Configuring the P2MP ISDN BRA Service360
- Example: Configuring the P2MP ISDN BRA Service(Based on the SIP Protocol)363
- Example: Configuring the ISDN PRA Service365
- Example: Configuring the ISDN PRA Service (Based on the SIP Protocol)369
- Example: Configuring TDM SHDSL for Carrying the PRA Service371
- Example: Configuring TDM SHDSL for Carrying the PRA Service (Based on the SIP Protocol)374
- Configuring Vags376
- Example: Configuring the H.248/MGCP-Based VAG Service376
- Example: Configuring the SIP-Based VAG Service383
- Example: Configuring the Triple Play388
- Configuration Example of the Triple Play (Multi-PVC for Multiple Services)390
- Configuration Example of the Triple Play (Single-PVC for Multiple Services) - Stream-Based Rate Limitation397
- Configuration Example of the Triple Play Service (Single-PVC for Multiple Services) - User-Based and Stream-Based Rate Limitation404
4 Configuration Example of the Private Line Service413
- Example: Configuring the Qinq VLAN415
- Example: Configuring VLAN Stacking Multi-ISP Wholesale Access419
- Configuration Example of the PWE3 Private Line Service423
- Example: Configuring ATM PWE3 to Implement Migration from ATM Network to IP Network424
- Example: Configuring the ATM PWE3 to Achieve Emulated ATM Services on the MPLS Network433
- Example: Configuring the ETH PWE3 to Emulate Ethernet Services on the MPLS Network439
- Example: Configuring the TDM PWE3 to Emulate TDM Services on the IP Network444
- Example: Configuring the TDM PWE3 to Emulate TDM Services on the MPLS Network450
- Configuration Example of TDM SHDSL for Transparently Transmitting the Narrowband Data Private Line Service455
- Configuration Example of the Private Line Service Leasing E1 Timeslots458
5 Configuration Example of MSTP Subtending Network464
- MSTP Networking465
- MSTP Dataplan466
- Configuring MA5600T/MA5603T/MA5608T-1470
- Configuring MA5600T/MA5603T/MA5608T-2480
- Configuring MA5600T/MA5603T/MA5608T-3490
- Configuring MA5600T/MA5603T/MA5608T-4498
- Configuring MA5600T/MA5603T/MA5608T-5506
- Verification512
6 Configuration Example of VPLS513
- Configuration Example of the VPLS Internet Access Service515
- Configuration Example of the VPLS Multicast Service519
- Configuration Example of the VPLS Enterprise Private Line Service524
7 Example: Subtending Networking531
- Subtended Network532
- Data Plan for Subtended Network533
- Configuring MA5600T-1536
- Configuring MA5600T-2545
- Configuring MA5600T-3555
- Configuring MA5600T-4562
- Verification567
8 Fttx Configuration Summary568
9 FTTH Configuration571
- FTTH Service Overview572
- Basic Concepts572
- Networking Scenarios and Hardware Configurations (GPON)574
- Networking Scenarios and Hardware Configurations (P2P)576
- Reference of GPON ONT Capability Sets577
- Principle of FTTH Data Plan588
- Data Plan Principles for IP Addresses588
- Principle of Qos Planning589
- Principle of Internet Access Service Data Plan592
- Principle of Voice Service Data Plan594
- Principle of IPTV Service Data Plan598
- Principle of Security Data Plan600
- GPON Access: Configuring FTTH Service602
- Bridging+Voice ONT Network Scenario603
- Service Requirements and Application Scenario603
- Configuration Process604
- Adding an ONT to an OLT607
- Configuring the Internet Access Service610
- Configuring the H.248-Based Voice Service (on a Web Page or the U2000)613
- Configuring the H.248-Based Voice Service (through the CLI)623
- Configuring the SIP-Based Voice Service (on a Web Page or the U2000)627
- Configuring the SIP-Based Voice Service (through the CLI)636
- Configuring the BTV Service641
- Configuring the Vod Service644
- Configuring Link Aggregation, Congestion Control, and Security Policies646
- Verifying Services649
- Bridging ONT + HGW Network Scenario654
- Service Requirements and Application Scenario654
- Configuration Process655
- Adding an ONT to an OLT656
- Configuring the Internet Access Service660
- Configuring the Voice Service663
- Configuring the BTV Service666
- Configuring the Vod Service670
- Configuring Link Aggregation, Congestion Control, and Security Policy673
- Verifying Services676
- Gateway ONT Network Scenario681
- Service Requirements and Application Scenario681
- Configuration Process682
- Adding an ONT to an OLT684
- Configuring the Internet Access Service (on a Web Page or the U2000)688
- Configuring the H.248-Based Voice Service (on a Web Page or the U2000)694
- Configuring the H.248-Based Voice Service (through the CLI)704
- Configuring the SIP-Based Voice Service (on a Web Page or the U2000)708
- Configuring the SIP-Based Voice Service (through the CLI)717
- Configuring the BTV Service722
- Configuring the Vod Service725
- Configuring Link Aggregation, Congestion Control, and Security Policy727
- Verifying Services730
- Configuring Triple Play Service (Simplified Mode)735
- P2P Access: Configuring FTTH Service742
10 FTTD Configuration749
- FTTD Service Overview750
- Basic Concepts750
- Networking Scenarios and Hardware Configurations (GPON)752
- Reference of GPON ONU Capability Sets755
- Principle of FTTD Data Plan756
- Data Plan Principles for IP Addresses756
- Principle of Qos Planning756
- Principle of Internet Access Service Data Plan759
- Principle of Voice Service Data Plan760
- Principle of IPTV Service Data Plan763
- GPON Access: Configuring FTTD Service765
- Bridging+Voice ONU Network Scenario (MA5652S)765
- Service Requirements and Application Scenario766
- Configuration Process766
- Adding an ONU to an OLT769
- Configuring a VDSL2 User Port772
- Configuring the Internet Access Service777
- Configuring the H.248-Based Voice Service (through the CLI)780
- Configuring the H.248-Based Voice Service (on a Web Page)784
- Configuring the SIP-Based Voice Service (through the CLI)790
- Configuring the SIP-Based Voice Service (on a Web Page)795
- Configuring the BTV Service800
- Configuring the Vod Service804
- Verifying Services807
- Bridging ONU Network Scenario (MA5651/MA5651S)811
- Service Requirements and Application Scenario811
- Configuration Process812
- Adding an ONU to an OLT813
- Configuring a VDSL2 User Port817
- Configuring the Internet Access Service822
- Configuring the Voice Service825
- Configuring the BTV Service828
- Configuring the Vod Service832
- Verifying Services835
11 FTTB and FTTC Solution Configuration839
- FTTB and FTTC Service Overview840
- Basic Concept840
- Scenario and Hardware Configuration (GPON)843
- Scenario and Hardware Configuration (10G GPON)846
- Networking Scenarios and Hardware Configurations (Ethernet Cascading)847
- GPON ONU Capability Sets849
- GPON ONU Capability Sets853
- Ethernet Upstream ONU Capability Sets854
- Principle of FTTB and FTTC Data Plan858
- Principle of Device Management Data Plan858
- Principle of Qos Data Plan860
- Principle of Internet Access Service Data Plan862
- Optional) Principle of Vectoring Data Plan865
- Principle of Voip Service Data Plan867
- Principle of IPTV Service Data Plan871
- Principle of Security Data Plan879
- Configuring Services in Various FTTB and FTTC Scenarios (GPON and 10G GPON Access)881
- FTTB Networking (LAN Access Without HGW)882
- Service Requirements and Application Scenarios882
- Configuration Procedure883
- Adding an ONU to an OLT885
- Configuring the Management Channel between the OLT and the ONU889
- Configuring the Service Channel between the OLT and the ONU890
- Configuring LAN Internet Access Service (on the ONU)892
- Configuring H.248 Voice Service (on the ONU)894
- Configuring SIP Voice Service (on the ONU)897
- Configuring Link Aggregation, Congestion Control, and Security Policies901
- Verifying Services904
- FTTB/C Networking (Xdsl Access, Without HGW)906
- Service Requirements and Application Scenario906
- Configuration Procedure907
- Adding an ONU to an OLT909
- Configuring the Management Channel between the OLT and the ONU913
- Configuring the Service Channel between the OLT and the ONU914
- Configuring the Internet Access Service (ADSL2+ Access, on the ONU)916
- Configuring the Internet Access Service (VDSL2 Access, on the ONU)919
- Optional) Configuring Vectoring922
- Configuring H.248 Voice Service (on the ONU)933
- Configuring SIP Voice Service (on the ONU)937
- Configuring Link Aggregation, Congestion Control, and Security Policy940
- Verifying Services943
- FTTB/FTTC+HGW Networking (Voice Service Provided by ONU)945
- Service Requirements and Application Scenario945
- Configuration Procedure947
- Adding an ONU to an OLT950
- Configuring the Management Channel between the OLT and the ONU954
- Configuring Service Channels between an OLT and an ONU955
- Configuring the Internet Access Service (LAN Access, on the ONU)959
- Configuring the Internet Access Service (ADSL2+ Access, on the ONU)960
- Configuring the Internet Access Service (VDSL2 Access, on the ONU)963
- Optional) Configuring Vectoring966
- Configuring H.248 Voice Service (on the ONU)977
- Configuring SIP Voice Service (on the ONU)981
- Configuring the IPTV Service (on the ONU)984
- Configuring Link Aggregation, Congestion Control, and Security Policy987
- Configuring the Internet Access Service (on the HGW)990
- Configuring the IPTV Service (on the HGW)992
- Verifying Services994
- FTTB/FTTC+HGW Networking (HGW Providing the Voip Service)998
- Service Requirements and Application Scenario998
- Configuration Procedure999
- Adding an ONU to an OLT1002
- Configuring the Management Channel between the OLT and the ONU1006
- Configuring the Service Channel between the OLT and the ONU1007
- Configuring the Internet Access Service (LAN Access, on the ONU)1011
- Configuring the Internet Access Service (ADSL2+ Access, on the ONU)1012
- Configuring the Internet Access Service (VDSL2 Access, on the ONU)1015
- Optional) Configuring Vectoring1018
- Configuring the Voice Service Channel (on the ONU)1029
- Configuring the IPTV Service (on the ONU)1031
- Configuring Link Aggregation, Congestion Control, and Security Policy1034
- Configuring the Internet Access Service (on the HGW)1037
- Configuring the IPTV Service (on the HGW)1039
- Configuring the Voip Service (on the HGW)1041
- Verifying Services1044
- Configuring Services in Various FTTB and FTTC Scenarios (Ethernet Cascading)1047
- FTTB and FTTC Ethernet Cascade Networking (ONU Works as an Independent NE)1047
- Service Requirements and Usage Scenario1047
- Configuration Procedure1049
- Configuring the Working Mode of an Ethernet Cascading Board1050
- Configuring the Management Channel between an OLT and an ONU1051
- Configuring the Service Channel between an OLT and an ONU1057
- Configuring the Service Flow on an ONU or HGW1061
- Configuring Link Aggregation, Congestion Control, and Security Policy1064
- Verifying Services1067
- FTTB and FTTC Ethernet Cascade Networking (ONU Works as a GE Remote Extended Subrack)1068
- Service Requirements and Application Scenarios for GE Remote Extended Subrack1068
- Principle of Data Planning for GE Remote Extended Subrack1069
- Configuration Procedure for GE Remote Extended Subrack1071
- Adding GE Remote Extended Subracks1073
- Configuring VDSL2 User Ports1074
- Configuring VDSL2 Service Flows1075
- Optional) Configuring Vectoring1078
- Configuring Link Aggregation, Congestion Control, and Security Policies1084
- Configuring the Internet Access Service (on the HGW)1088
- Configuring the IPTV Service (on the HGW)1090
- Configuring the Voip Service (on the HGW)1092
- Verifying Services1094
12 FTTO Configuration(SOHO and SME)1098
- Overview of FTTO Services (SOHO and SME)1099
- Basic Concept1099
- Networking Scenario and Hardware Configurations1101
- ONU Capability Sets1103
- Principles of Planning Data for FTTO Services (SOHO and SME)1105
- Principles of Planing Device Management Data1105
- Principle of Qos Planning1107
- Principle of Internet Access Service Data Plan1110
- Principles of Planning Voice Service Data1111
- Principle of IPTV Service Data Plan1115
- Principle of Security Data Plan1116
- Principle of Reliability Data Plan1119
- SOHO Service Configuration (GPON)1121
- Service Requirements and Usage Scenario1121
- Configuration Procedure1123
- Adding an ONU to an OLT1124
- Configuring the Internet Access Service1128
- Configuring the H.248-Based Voice Service (on a Web Page)1132
- Configuring the H.248-Based Voice Service (through the CLI)1139
- Configuring the SIP-Based Voice Service (on a Web Page)1144
- Configuring the SIP-Based Voice Service (through the CLI)1151
- Configuring the BTV Service1156
- Configuring the Vod Service1159
- Configuring Link Aggregation, Congestion Control, and Security Policy1160
- Verifying Services1163
- SME Service Configuration (GPON)1168
- Bridging and Router Networking1168
- Service Requirements and Usage Scenario1168
- Configuration Procedure1169
- Adding an ONU to an OLT1171
- Configuring the Internet Access Service1175
- Configuring the H.248-Based Voice Service (on a Web Page)1177
- Configuring the H.248-Based Voice Service (through the CLI)1184
- Configuring the SIP-Based Voice Service (on a Web Page)1187
- Configuring the SIP-Based Voice Service (through the CLI)1194
- Configuring the BTV Service1199
- Configuring the Vod Service1202
- Configuring Link Aggregation, Congestion Control, and Security Policy1205
- Verifying Services1208
- Gateway Networking1212
- Service Requirements and Usage Scenario1212
- Configuration Procedure1213
- Adding an ONU to an OLT1215
- Configuring the Internet Access Service1219
- Configuring the H.248-Based Voice Service (on a Web Page)1223
- Configuring the H.248-Based Voice Service (through the CLI)1230
- Configuring the SIP-Based Voice Service (on a Web Page)1234
- Configuring the SIP-Based Voice Service (through the CLI)1241
- Configuring the BTV Service1247
- Configuring the Vod Service1250
- Configuring Link Aggregation, Congestion Control, and Security Policy1251
- Verifying Services1254
- Layer 2 Interoperation Service between Enterprise Branches1259
- Service Requirement and Application Scenario1259
- Configuration Procedure1260
- Adding Onus to OLT1262
- Configuring Layer 2 Interoperation Service Ports on OLT1266
- Configuring Congestion Control and Security Policies1267
- Configuring E2E Reliability1268
- Verifying Services1272
13 FTTO Configuration (Large-Sized Enterprise Access)1275
- Overview of Enterprise Access Service1276
- Basic Concepts1276
- Networking Scenarios and Hardware Configurations (GPON)1279
- GPON ONU Capability Set1280
- Principle of Planning Data for Enterprise Access Service1282
- Principle of Equipment Management Data Plan1282
- Principle of VLAN Data Plan1283
- Principle of Qos Data Plan1285
- Principle of Protocol Transparent Transmission Data Plan1288
- Principle of Security Data Plan1289
- Principle of Reliability Data Plan1291
- Configuring Enterprise Access Service (GPON)1293
- Layer 2 Interoperation Service between Enterprise Branches1294
- Service Requirement and Application Scenario1294
- Configuration Process1295
- Adding Onus to OLT1296
- Configuring Management Service Ports on OLT and Onus1300
- Configuring Layer 2 Interoperation Service Ports on OLT1301
- Configuring Ethernet Access Service Ports on Onus1303
- Configuring Congestion Control and Security Policies1304
- Configuring E2E Reliability1306
- Verifying Services1310
- Enterprise DDN Private Line Access Service1312
- Service Requirement and Application Scenario1312
- Configuration Process1313
- Adding Onus to OLT1314
- Configuring Management Service Ports on OLT and Onus1317
- Configuring TDM Connections1318
- Configuring Clock Synchronization1319
- Verifying Services1321
- Enterprise IP PBX Private Line Access Service1324
- Service Requirement and Application Scenario1324
- Configuration Process1325
- Adding Onus to OLT1326
- Configuring Management Service Ports on OLT and Onus1328
- Configuring OLT Qinq Service Ports1329
- Configuring Ethernet Access Service Ports on Onus1330
- Configuring Congestion Control and Security Policies1331
- Configuring E2E Reliability1333
- Verifying Services1337
- Enterprise PRA PBX Private Line Access Service1338
- Service Requirement and Application Scenario1338
- Configuration Process1339
- Adding Onus to OLT1339
- Configuring Management Service Ports on OLT and Onus1342
- Configuring Service Ports for Voice Transparent Transmission1343
- Configuring Voip PRA Access1344
- Configuring Congestion Control and Security Policies1347
- Configuring E2E Reliability1348
- Verifying Services1352
- Enterprise E1 Unified Access Service1353
- Service Requirement and Application Scenario1353
- Configuration Process1353
- Adding Onus to OLT1355
- Configuring Management Service Ports on OLT and Onus1357
- Configuring Satop Connections and Service Ports1358
- Configuring ONU Satop Connections1361
- Configuring Clock Synchronization1362
- Configuring Congestion Control and Security Policies1364
- Configuring Network Protectio1366
- Verifying Services1368
- Enterprise E1/T1 Unified Access Service (OLT Cascading)1370
- Service Requirement and Application Scenario1370
- Configuration Process1371
- Configure OLT_A Cascading with OLT_B1372
- Configuring Satop Connections between OLT_A and ONU1373
- Adding Onus to OLT_B1374
- Configuring Management and Service Channel on OLT_B and ONU1377
- Configuring ONU Satop Connections1378
- Configuring Clock Synchronization1380
- Verifying Services1382
14 FTTM Configuration (Base Station Access)1385
- Overview of Base Station Access Service1386
- Basic Concepts1386
- Networking Scenarios and Hardware Configurations (GPON)1387
- GPON ONU Capability Set1389
- Prinpicle of Planning Data for Base Station Access Service1391
- Principle of Equipment Management Data Plan1391
- Principle of VLAN Data Plan1392
- Principle of Qos Data Plan1394
- Principle of Clock Synchronization Data Plan1395
- Principle of Security Data Plan1397
- Planning Reliability Data1398
- Configuring Base Station Access Clock Synchronization1401
- Overview of Base Station Access Clock/Time Synchronization1401
- Configuring BITS Clock Synchronization1406
- Configuring E1/STM-1 Line Clock Synchronization1409
- Configuring Ethernet Clock Synchronization1411
- Configuring "1Pps+Tod" Clock Synchronization1414
- Configuring 1588V2 Clock Synchronization1418
- Configuring Base Station Access Service (GPON)1424
- E1 Base Station Access Service (in Native TDM Mode)1424
- Service Requirement and Application Scenario1424
- Configuration Process1425
- Adding Onus to OLT1426
- Configuring Management Service Ports on OLT and Onus1429
- Configuring TDM E1 Connections1430
- Configuring Clock Synchronization1431
- Configuring Congestion Control and Security Policies1433
- Configuring Network Protection1435
- Verifying Services1436
- E1 Base Station Access Service (in Satop Mode)1439
- Service Requirement and Application Scenario1439
- Configuration Process1440
- Adding Onus to OLT1442
- Configuring Management Service Ports on OLT and Onus1444
- Configuring Satop Connections and Service Ports1445
- Configuring Clock Synchronization1448
- Configuring Congestion Control and Security Policies1450
- Configuring Network Protection1451
- Configuring ONU Satop Connections1453
- Verifying Services1455
- Ethernet Base Station Access Service (in Qinq VLAN Mode)1457
- Service Requirement and Application Scenario1457
- Configuration Process1458
- Adding Onus to OLT1459
- Configuring Management Service Ports on OLT and Onus1462
- Configuring OLT Qinq Vlans and Service Ports1463
- Configuring Ethernet Access Service Ports on Onus1465
- Configuring Clock Synchronization1467
- Configuring Congestion Control and Security Policies1468
- Configuring Network Protection1470
- Verifying Services1474
- Symmetrical TDM PWE3 Access for Olts on both Sides1474
- Service Requirements and Application Scenario1474
- Configuration Procedure1475
- Adding Onus to the OLT and Configuring the Management Service Port1476
- Configuring the TDM Connection and TDM PW1479
- Configuring Clock Synchronization1482
- Configuring Congestion Control and Security Policies1483
- Configuring E2E Reliability1485
- Verifying Services1489
- GPON Access for the OLT One Side and E1 or SHDSL Access for the OLT on the Peer Side1490
- Service Requirements and Application Scenario1490
- Configuration Procedure1491
- Adding Onus to OLT-A and Configuring the Management Service Port1491
- Configuring the TDM Connection and TDM PW1495
- Configuring Clock Synchronization1498
- Configuring E2E Reliability1499
- Verifying Services1503
- Symmetrical E1 or SHDSL Access for Olts on both Sides1504
- Service Requirements and Application Scenario1504
- Configuration Procedure1505
- Configuring the TDM Connection and TDM PW1505
- Configuring Clock Synchronization1508
- Verifying Services1509
- E1 Access for the ONU and TDM PWE3 between the ONU and Peer PE1511
- Service Requirements and Application Scenario1511
- Configuration Procedure1511
- Adding Onus to the OLT and Configuring the Management Service Port1512
- Configuring the TDM VCL and Cesop Connection on the ONU1515
- Configuring the Static LSP and PW on the CX6001517
- Configuring Clock Synchronization1518
- Verifying Services1520
- Small-Cell Base Station Access Service (in Qinq VLAN through CLI Configuration)1521
- Service Requirements and Application Scenarios1521
- Configuration Procedure1522
- Configuring Ethernet Access Service Ports on Onus1522
- Configuring Congestion Control and Security Policies1524
- Configuring Clock Synchronization1525
- Configuring End to End Protection1527
- Verifying Services1528
- Small-Cell Base Station Access Service (in Qinq VLAN Mode through GUI Pre-Deployment)1528
- Service Requirements and Application Scenarios1529
- Configuration Procedure1529
- Configuring the IP Address of the NMS Server and the IP Address Pool of the ONU (GPON Dock Scenario)1530
- Creating the Authentication-Free Policy and Associating It with the OLT (GPON Dock Scenario)1532
- Configuring the Remote Software Commissioning Policy (GPON Dock Scenario)1536
- Configuring Clock Synchronization1537
- Verifying Services1539
15 Opticable D-CMTS Configuration (MA5633 Working as a Remote Extended Frame)1540
- D-CMTS Service Overview1542
- Basic Concepts1542
- Networking Scenarios and Hardware Configurations (GPON)1547
- Networking Scenarios and Hardware Configurations (GE)1548
- Data Plan Principles for D-CMTS Services1549
- Frequency Spectrum Management1549
- Device Management1551
- Qos1551
- Vlan1555
- VLAN Planning for Telecom Networks1557
- Service Configuration on a D-CMTS that Works as a GPON Remote Extended Frame on a Layer 3 Network1560
- Home Service Networking1561
- Service Requirements and Usage Scenario1561
- Configuration Process1562
- Configuring DHCP Relay1565
- Configuring a Route1567
- Configuring DHCP Relay (Ipv6)1569
- Configuring a Route (Ipv6)1572
- Adding a Remote Extended Frame to an OLT1574
- Configuring RF Port Parameters1577
- Configuring the HSI Service1581
- Configuring the DOCSIS Vod Service1582
- Configuring the EQAM Vod Service1583
- Configuring the BTV Service1586
- Configuring the Dynamic Packetcable Service1588
- Verifying Services1589
- L2VPN Enterprise Service Networking1594
- Service Requirements and Usage Scenario1594
- Configuration Process1595
- Configuring DHCP Relay1596
- Configuring a Route1598
- Configuring DHCP Relay (Ipv6)1600
- Configuring a Route (Ipv6)1602
- Adding a Remote Extended Frame to an OLT1604
- Configuring RF Port Parameters1606
- Configuring the L2VPN Enterprise Service1610
- Verifying Services1611
- WLAN Hotspot Radio Backhaul Service Networking1615
- Service Configuration on a D-CMTS that Works as a GE Remote Extended Frame on a Layer 3 Network1616
- Home Service Networking1617
- Service Requirements and Usage Scenario1617
- Configuration Process1618
- Configuring DHCP Relay1620
- Configuring a Route1623
- Configuring DHCP Relay (Ipv6)1625
- Configuring a Route (Ipv6)1628
- Adding a Remote Extended Frame to an OLT1630
- Configuring RF Port Parameters1632
- Configuring the HSI Service1636
- Configuring the DOCSIS Vod Service1637
- Configuring the EQAM Vod Service1638
- Configuring the BTV Service1641
- Configuring the Dynamic Packetcable Service1643
- Verifying Services1644
- L2VPN Enterprise Service Networking1649
- Service Requirements and Usage Scenario1649
- Configuration Process1649
- Configuring DHCP Relay1651
- Configuring a Route1653
- Configuring DHCP Relay (Ipv6)1654
- Configuring a Route (Ipv6)1656
- Adding a Remote Extended Frame to an OLT1658
- Configuring RF Port Parameters1661
- Configuring the L2VPN Enterprise Service1664
- Verifying Services1666
- WLAN Hotspot Radio Backhaul Service Networking1669
- Service Configuration on a D-CMTS that Works as a GPON Remote Extended Frame on a Layer 2 Telecom Network1670
- Home Service Networking1671
- Service Requirements and Usage Scenario1671
- Configuration Process1672
- Adding a Remote Extended Frame to an OLT1674
- Configuring RF Port Parameters1677
- Configuring the HSI Service1680
- Configuring the DOCSIS Vod Service1681
- Verifying Services1682
16 Opticable D-CMTS Configuration (MA5633 Working as a Standalone NE)1687
- D-CMTS Service Overview1689
- Basic Concepts1689
- Networking Scenarios and Hardware Configurations1693
- Data Plan Principles for D-CMTS Services1694
- Frequency Spectrum Management1694
- Device Management1696
- Qos1697
- Vlan1700
- Service Configuration on a D-CMTS that Works in GE Access Mode on a Layer 3 Network1704
- Home Service Networking1704
- Service Requirements and Usage Scenario1704
- Configuration Process1705
- Configuring DHCP Relay1708
- Configuring a Route1710
- Configuring DHCP Relay (Ipv6)1712
- Configuring a Route (Ipv6)1714
- Configuring a Management Channel between an OLT and a D-CMTS1717
- Configuring a Service Channel between an OLT and a D-CMTS1719
- Configuring RF Port Parameters on a D-CMTS1721
- Configuring the HSI Service on a D-CMTS1723
- Configuring the DOCSIS Vod Service on a D-CMTS1724
- Configuring the EQAM Vod Service on a D-CMTS1725
- Configuring the BTV Service1728
- Configuring the Dynamic Packetcable Service on a D-CMTS1730
- Verifying Services1732
- L2VPN Enterprise Service Networking1736
- Service Requirements and Usage Scenario1736
- Configuration Process1736
- Configuring DHCP Relay1738
- Configuring a Route1739
- Configuring DHCP Relay (Ipv6)1741
- Configuring a Route (Ipv6)1743
- Configuring a Management Channel between an OLT and an MA56331745
- Configuring a Service Channel between an OLT and a D-CMTS1747
- Configuring RF Port Parameters on an MA56331749
- Configuring the L2VPN Enterprise Service(on the CMC)1751
- Verifying Services1752
- WLAN Hotspot Radio Backhaul Service Networking1756
- Service Configuration on a D-CMTS that Works in GPON Access Mode on a Layer 3 Network1757
- Home Service Networking1758
- Service Requirements and Usage Scenario1758
- Configuration Process1759
- Configuring DHCP Relay1761
- Configuring a Route1764
- Configuring DHCP Relay (Ipv6)1766
- Configuring a Route (Ipv6)1768
- Adding a D-CMTS to an OLT1770
- Configuring a Management Channel between an OLT and a D-CMTS1775
- Configuring a Service Channel between an OLT and a D-CMTS1776
- Configuring RF Port Parameters on an MA56331778
- Configuring the HSI Service on an MA56331780
- Configuring the DOCSIS Vod Service on an MA56331781
- Configuring the EQAM Vod Service on an MA56331782
- Configuring the BTV Service on an MA56331785
- Configuring the Dynamic Packetcable Service on an MA56331787
- Verifying Services1789
- L2VPN Enterprise Service Networking1793
- Service Requirements and Usage Scenario1793
- Configuration Process1793
- Configuring DHCP Relay1796
- Configuring a Route1797
- Configuring DHCP Relay (Ipv6)1799
- Configuring a Route (Ipv6)1801
- Adding a D-CMTS to an OLT1803
- Configuring a Management Channel between an OLT and an MA56331807
- Configuring a Service Channel between an OLT and a D-CMTS1809
- Configuring RF Port Parameters on an MA56331811
- Configuring the L2VPN Enterprise Service on an MA56331813
- Verifying Services1814
- WLAN Hotspot Radio Backhaul Service Networking1818
17 Electrical Service Configuration1820
- Configuration Example of the Fttx Service (GPON Access)1821
- Configuration Example of Transmitting Video Monitoring Data over Ethernet Access1821
- Configuration Example of Intelligently Collecting Power Consumption Information over Ethernet Access1830
- Configuration Example of Automatically Transmitting Site Information over Ethernet (Single Homing)1839
- Configuration Example of Automatically Transmitting Site Information over Ethernet (Dual Homing)1856
- Configuration Example of Transmitting Information Collected in Centralized Mode in the Smart Grid over a Serial Port1872
- Configuration Description1874
18 Opticable Eoc Bandwidth Configuration1884
- Configuring Example of Eoc Services (Olts Use GPON Access)1885
19 Ipv6 Configuration1896
- Ipv6 Networking1897
- Configuration Difference between Ipv6 and Ipv41899
- Configuration Differences between Ipv6 and Ipv4 on the OLT1899
- Configuration Differences between Ipv6 and Ipv4 on the ONU1903
- Configuration Difference between Ipv6 and Ipv4 on the ONT1908
- Configuring Ipv6 Services in the FTTB/C (no Hgws) Scenario1909
- Application Scenarios1909
- Data Planning1910
- Configuration Procedure1912
- Configuration Example1914
- Configuring Ipv6 Services in the FTTB+HGW Scenario1922
- Application Scenario1922
- Data Planning1923
- Configuration Procedure1927
- Configuration Example1929
- Configuring Ipv6 Services in the FTTH (Bridging ONT) Scenario1940
- Application Scenarios1940
- Data Planning1941
- Configuration Procedure1944
- Configuration Example1945
- Configuring Ipv6 Services in the FTTH (Gateway ONT) Scenario1959
- Application Scenarios1959
- Data Plan1960
- Configuration Procedure1963
- Configuration Example1964

Brand	Huawei
Model	SmartAX MA5600T
Category	Control Unit
Language	English

Huawei SmartAX MA5600T User Manual

Table of Contents

Other manuals for Huawei SmartAX MA5600T

Questions and Answers:

Huawei SmartAX MA5600T Specifications

Related product manuals
