Table 15-10 Methods of adding a remote extended frame to an OLT
Method Usage Scenario Remarks
Add a remote
extended frame
in offline mode.
A carrier has planned all remote
extended frame IDs together and
the remote extended frames
must be deployed one by one.
This method facilitates remote
extended frame management.
1. You have obtained the serial
number (SN) of the remote
extended frame.
2. The remote extended frame ID has
been planned.
Add an
automatically
discovered
remote extended
frame.
A great number of remote
extended frames need to be
deployed. This method reduces
manual configurations.
1. You do not know the SN of the
remote extended frame.
2. The remote extended frame ID
does not need to be planned.
Data Plan
Table 15-11 Data plan
Item Data
GPON cascading
board
Board: H801GPMD
Port ID: 0/3/1
Remote extended frame ID: 1
Remote extended frame authentication mode: SN
Remote extended frame SN: 48575443E6D8B541
NOTE
The OLT uses the MA5603T as an example. The configuration method is the
same for other OLTs. The only difference lies in slot IDs.
Dynamic
bandwidth
allocation (DBA)
Profile: default
Type: type4
Maximum bandwidth: 1000 Mbit/s
Line profile Profile: default
GPON encapsulation mode (GEM) port ID: 0 (fixed port in centralized
management mode)
Transmission container (T-CONT) ID: 1 (fixed T-CONT in centralized
management mode)
MA5633
management
mode
extend-frame
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
15 OptiCable D-CMTS Configuration (MA5633 Working as
a Remote Extended Frame)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1550
