Data Plan
The following table provides key information about the service channels between an OLT and
an ONU.
Service
Type
VLAN Plan Remarks
Internet
access
service
S-VLAN ID: 100; S-
VLAN attribute:
stacking
C-VLAN ID: 1000-1016
Plan the Internet access service in per user per
service per VLAN (PUPSPV) mode and apply S-
VLAN+C-VLAN to differentiate users.
For details, see 11.2.3 Principle of Internet
Access Service Data Plan.
VoIP
service
S-VLAN ID: 200
C-VLAN ID: 200
The voice over IP (VoIP) service is a carrier-
operating, closed service and primarily adopts only
S-VLAN tags, which are transparently transmitted
by OLTs.
For details, see 11.2.5 Principle of VoIP Service
Data Plan.
VoD
service
S-VLAN ID: 300 Plan the video on demand (VoD) service in per user
per VLAN (PUPV) mode if possible, as the VoD
service requires only a few VLAN resources.
The VoD service is a carrier-operating, closed
service and primarily adopts only S-VLAN tags,
which are transparently transmitted by OLTs.
For details, see 11.2.6 Principle of IPTV Service
Data Plan.
Multicast
service
Multicast VLAN ID:
1000
Multicast cascading port:
0/2/1
IGMP version: IGMPv3
IGMP mode: IGMP
proxy
Multicast IP address
range:
224.1.1.10-224.1.1.100
IP address of the
multicast server:
10.10.10.10/24
The multicast service is a carrier-operating, closed
service and primarily adopts only S-VLAN tags.
For details, see 11.2.6 Principle of IPTV Service
Data Plan.
NOTE
C-VLANs in the preceding table are defined for OLTs. That is, they are upstream VLANs or S-VLANs of ONUs.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
11 FTTB and FTTC Solution Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
983
