Parameter Value
VLANID
[1-4094]
Multicast VLAN ID corresponding to the user VLAN value
for multicast service flows created on the ONU. In this
example, set this parameter to 43.
Binding item LAN4
Mode Bridge
DHCP
transparent
transmission
Enable
c. Click OK to save the settings.
3. Restart the HGW.
Choose Management > Device Management and click Restarting the Device.
l Configure the IPTV service on the HG527.
1. Log in to the Web configuration window.
a. Enter http://192.168.1.1/cnc.html (default IP address) to the address bar of the
IE and press Enter.
b. In the login dialog box, enter the user name (default: admin) and password
(default: admin) of the administrator. Then, click OK.
2. Configure multicast parameters.
This example assumes LAN 4 as an IPTV port.
a. Choose Network > Bandwidth Configuration from the navigation tree.
b. In the right pane, create LAN connection 1 for dialup Internet access services.
Set the parameters as follows:
Parameter Value
Bearing
service
OTHER: The connection is used for the IPTV service.
Enabling The LAN connection is enabled when this check box is
selected.
VLAN
enabling
Enable: VLAN tags are added to upstream packets.
NOTE
When multicast service flows are created on the ONU, the value is
Disable if uservlan is untagged and the value is Enable if
uservlan is tagged.
VLANID
[1-4094]
Multicast VLAN ID on the HGW when multicast service
flows are created on the ONU. In this example, set this
parameter to 43.
VPI/VCI Set the VPI/VCI to the same as that configured on the devices
at the central office. In this example, set this parameter to
0/35.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 11 FTTB and FTTC Solution Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1066
