Parameter Default Value
Analog parameters ESC analog parameter IDs:
l 0: allocated to the board temperature sensor by default (unable to
be changed by the user).
l 1-4: allocated to the voltage sensor by default.
– 1 indicates -48 V input of channel 0.
– 2 indicates -48 V input of channel 1.
– 3 indicates -48 V input of channel 2.
– 4 indicates -48 V input of channel 3.
l 5-8: user-defined analog parameters allocated to other extended
analog sensors, such as the temperature sensor and the humidity
sensor.
Upper and lower alarm thresholds
l Temperature: 5°C to 55°C
l Humidity: 0% RH to 80% RH
Digital parameters ESC digital parameter IDs
l Allocated by default (unable to be changed by the user)
– 0: MDF
– 1: door status sensor 0
– 9: water
– 10-13: lightning arresters 0-3
– 14-15: switches 11 and 12
– 16-17: switches 21 and 22
– 18-19: switches 31 and 32
– 20-21: switches 41 and 42
– 22: external sensor power
l User-defined IDs
– 2-8: allocated to other extended digital sensors.
Procedure
Step 1 Set the DIP switch of the sub-node for the H801ESC board. By default, the sub-node ID is 15.
The H801ESC board communicates with the MA5600T/MA5603T/MA5608T in the master
node and sub-node mode. Therefore, the DIP switch of the sub-node for the H801ESC board
must be consistent with that for the MA5600T/MA5603T/MA5608T. For details about how to
configure the DIP switches of the H801ESC board, see the Description of DIP Switches in
1.3.1.1 Checking the Settings of DIP Switches on the H801ESC Board.
Step 2 Insert the H801ESC board into the corresponding slot of the PDU, and make sure that the
MA5600T/MA5603T/MA5608T and the H801ESC board are connected through the RS-485
serial port cable.
