Data Plan
Table 12-3 Data plan
Item Data
DBA profile Profile name: ftto_dba
Profile type: type3
Assured bandwidth: 8 Mbit/s
Maximum bandwidth: 50 Mbit/s
ONU line profile Profile name: ftto_line
T-CONT ID: 4
GEM port ID for management services: 11
GEM port ID for voice services: 12
GEM port ID for video services: 13
GEM port ID for Internet access services: 14
ONU service
profile
Profile name: ftto_ser
ONU port capability set: adaptive
Network
topology data
PON port: 0/1/0
ONU IDs: 1 and 2
Procedure
Step 1 Configure GPON ONU profiles.
GPON ONU profiles include the DBA profile, line profile, service profile, and alarm profile.
l DBA profile: A DBA profile describes GPON traffic parameters. A T-CONT is bound to a
DBA profile for dynamic bandwidth allocation, improving upstream bandwidth utilization.
l Line profile: A line profile describes the binding between the T-CONT and the DBA profile,
the QoS mode of the traffic stream, and the mapping between the GEM port and the ONU-
side service.
l Service profile: A service profile provides the service configuration channel for the ONU
that is managed by using optical network terminal management and control interface
(OMCI).
l Alarm profile: An alarm profile contains a series of alarm thresholds to measure and monitor
the performance of activated ONU lines. When a statistical value reaches the threshold, the
host is notified and an alarm is reported to the log host and the NMS.
1. Configure a DBA profile.
Run the display dba-profile command to query existing DBA profiles in the system. If the
existing DBA profiles in the system do not meet the requirements, run the dba-profile
add command to add a DBA profile.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
12 FTTO Configuration(SOHO and SME)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1100
