Run the display traffic table ip command to query existing traffic profiles in the
system. If the existing traffic profiles in the system do not meet the requirements, run
the traffic table ip command to add a traffic profile.
huawei(config)#traffic table ip name ftto_voip cir off priority 5 priority-
policy
local-setting
2. Configure the mapping between a GEM port and a VLAN. Create a service VLAN
and a service flow.
Table 12-11 Scenario plan
Scenario VLAN Plan VLAN Translation Policy
Scenario 1 Single VLAN tag
l S-VLAN ID: 300
l S-VLAN type: smart
l S-VLAN attribute:
common
l C-VLAN ID: 300
ONU: Configure a VLAN
for all ONUs and add the
same C-VLAN tag to
packets. All ONUs are in the
same C-VLAN.
OLT: The OLT transparently
transmits VLAN tags (the C-
VLAN is the same as the
planned S-VLAN).
Scenario 2 Single VLAN tag
l S-VLAN ID: 300
l S-VLAN type: smart
l S-VLAN attribute:
common
l C-VLAN ID: 3001
ONU: Configure a VLAN
for all ONUs and add the
same C-VLAN tag to
packets. All ONUs are in the
same C-VLAN.
OLT: The OLT switches
between C-VLAN tags and
S-VLAN tags (C-VLAN is
different from the planned S-
VLAN).
Scenario 1:
Configure the mapping between a GEM port and a VLAN. The service flow of user
VLAN 300 is mapped to GEM port 12 in the ONU line profile.
huawei(config)#ont-lineprofile gpon profile-name ftto_line
huawei(config-gpon-lineprofile-1)#gem mapping 12 2 vlan 300
huawei(config-gpon-lineprofile-1)#commit
huawei(config-gpon-lineprofile-1)#quit
Create a service VLAN and add an upstream port to it. Add upstream port 0/19/0 to
VLAN 300.
huawei(config)#vlan 300 smart
huawei(config)#port vlan 300 0/19 0
Create service flows. Set the service VLAN to 300, GEM port ID to 12, and user
VLAN to 300, and use traffic profile ftto_voip.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
12 FTTO Configuration(SOHO and SME)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1120
