Procedure
l Configure the OLT.
1. Configure a traffic profile.
Run the display traffic table ip command to query existing traffic profiles in the
system. If the traffic profiles existing in the system do not meet the requirements, you
need to run the traffic table ip command to add a traffic profile.
Set the profile ID to ftto_hsi, the CIR to 4 Mbit/s, and the priority to 0. In addition,
configure the scheduling mode so that packets are scheduled according to their
priorities.
huawei(config)#traffic table ip name ftto_hsi cir 4096 priority 0 priority-
policy local-setting
2. Configure the mapping between a GEM port and a VLAN. Create a VLAN and a
service flow.
Table 12-20 Scenario plan
Scenario VLAN Plan VLAN Translation Policy
bridging ONU +
Router
Double-tagged
VLAN
l S-VLAN ID: 100
l S-VLAN type:
smart
l S-VLAN
attribute:
stacking
l C-VLAN ID:
1001-1002
l U-VLAN ID: 45
ONU: The upstream packets sent
from the router carry C-VLAN tags
and the ONU transparently
transmits them.
OLT: The OLT switches between
the U-VLAN tag and the S-VLAN
+C-VLAN tag.
Configure the mapping between a GEM port and a VLAN. The service flow of user-
side VLAN 45 is mapped to GEM port 14 in the ONU line profile.
NOTE
Here, the user-side VLAN is the VLAN carried by packets sent from HGW to ONU, namely, U-
VLAN.
huawei(config)#ont-lineprofile gpon profile-name ftto_line
huawei(config-gpon-lineprofile-1)#gem mapping 14 0 vlan 45
huawei(config-gpon-lineprofile-1)#commit
huawei(config-gpon-lineprofile-1)#quit
Configure the VLAN of the Ethernet port on the ONU. add Ethernet port 1 to VLAN
45 in the ONU service profile.
huawei(config)#ont-srvprofile gpon profile-name ftto_ser
huawei(config-gpon-srvprofile-1)#port vlan eth 1 45
huawei(config-gpon-srvprofile-1)#commit
