Create a service VLAN and add an upstream port to it. Add upstream port 0/19/0 to VLAN
1100.
huawei(config)#vlan 1100 smart
huawei(config)#port vlan 1100 0/19 0
Create service flows. Set the service VLAN to 1100, GEM port ID to 13, and user VLAN
to 43, and use traffic profile 8.
huawei(config)#service-port 3 vlan 1100 gpon 0/1/0 ont 1 gemport 13
rx-cttr 8 tx-cttr 8 tag-transform transparent
huawei(config)#service-port 4 vlan 1100 gpon 0/1/0 ont 2 gemport 13
rx-cttr 8 tx-cttr 8 tag-transform transparent
3. Perform this step in the bridging ONU+router (double VLAN tags) scenario.
Table 12-33 Data plan
VLAN Plan VLAN Translation Policy
l S-VLAN ID: 1100
l VLAN type: smart
l VLAN attribute: stacking
l C'-VLAN: 2010
l C-VLAN: 2001
The ONU adds C-VLAN tags to packets.
All ONUs are in the same C-VLAN.
The OLT switches between the C-VLAN
tag and the S-VLAN+C'-VLAN tag.
Configure the mapping between a GEM port and a VLAN. The service flow of user VLAN
2001 is mapped to GEM port 13 in the ONU line profile.
huawei(config)#ont-lineprofile gpon profile-name ftto_line
huawei(config-gpon-lineprofile-1)#gem mapping 13 4 vlan 2001
huawei(config-gpon-lineprofile-1)#commit
huawei(config-gpon-lineprofile-1)#quit
Configure the VLAN of the Ethernet port on the ONU. If the ONU is connected to the STB
through Ethernet port 2, add Ethernet port 2 to VLAN 2001.
huawei(config)#ont-srvprofile gpon profile-name ftto_ser
huawei(config-gpon-srvprofile-1)#port vlan eth 2 2001
huawei(config-gpon-srvprofile-1)#commit
huawei(config-gpon-srvprofile-1)#quit
Create a service VLAN and add an upstream port to it. Set the attribute of VLAN 1100 to
stacking. Add upstream port 0/19/0 to VLAN 1100.
huawei(config)#vlan 1100 smart
huawei(config)#vlan attrib 1100 stacking
huawei(config)#port vlan 1100 0/19 0
Create service flows. Set the service VLAN to 1100, GEM port ID to 13, and user VLAN
to 2001, and use traffic profile 8. Set the VLAN translation policy to Translate and Add to
translate the C-VLAN 2001 to C'-VLAN 2010.
huawei(config)#service-port 3 vlan 1100 gpon 0/1/0 ont 1 gemport 13
multi-service user-vlan 2001 tag-transform translate-and-add inner-vlan 2010
rx-cttr 8 tx-cttr 8
huawei(config)#service-port 4 vlan 1100 gpon 0/1/0 ont 2 gemport 13
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
12 FTTO Configuration(SOHO and SME)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1179
