Figure 12-10 Configuration procedure in the FTTO SME scenario

The following table lists the detailed description steps.

Item Procedure Remarks

OLT Adding an ONU to an OLT Services can be configured for an ONU only

after the ONU is successfully added to an

OLT.

OLT

ONU

Configuring the Internet Access

Service

OLT

ONU

Configuring the

Voice Service

Configuring

the H.248-

based Voice

Service (on a

Web Page)

NOTE

The H.248 and SIP protocols are mutually

exclusive for the VoIP service. Only one of them

is configured at a time.

Configuring

the H.248-

based Voice

Service

(Through the

CLI)

SmartAX MA5600T/MA5603T/MA5608T Multi-service

Access Module

Commissioning and Configuration Guide 12 FTTO Configuration(SOHO and SME)

Issue 01 (2014-04-30) Huawei Proprietary and Confidential

1189
