Item Data Plan for the F01D500 Cabinet
Digital parameter ID: 4
This digital parameter is set according to the actual requirements.
The monitoring digital parameter of the smoke sensor is set here
to monitor whether there is smoke in the actual environment.
When there is smoke, the host reports an alarm.
Valid level of digital parameter 4: high level
When the high level represents the valid level, the host does not
report an alarm in the case of high level.
Digital parameter ID: 5
This digital parameter is set according to the actual requirements.
The monitoring digital parameter of the heat exchanger is set here
to monitor the status of the heat exchanger. When the heat
exchanger is faulty, the host reports an alarm.
Valid level of digital parameter 5: low level
When the low level represents the valid level, the host does not
report an alarm in the case of low level.
Digital parameter ID: 6
This digital parameter is set according to the actual requirements.
The digital monitoring parameter of the MDF door status sensor
is set here to monitor the MDF door status. When the door of the
MDF compartment is open, the host reports an alarm.
Valid level of digital parameter 6: low level
When the low level represents the valid level, the host does not
report an alarm in the case of low level.
NOTE
The preceding data is configured according to the actual requirements. When the actually planned value
of a parameter is the same as the default value, it is not necessary to configure the parameter.
Configuration Example
The following considers the configuration in the F01D500 cabinet as an example to describe the
process of configuring the environment monitoring parameters of the GEPS4845.
huawei(config)#emu add 0 POWER4845 0 0 POWER4845
huawei(config)#display emu 0
huawei(config)#interface emu 0
huawei(config-if-power4845-0)#display power system parameter
huawei(config-if-power4845-0)#display power environment parameter
huawei(config-if-power4845-0)#power battery parameter 1 0.15 60 150
huawei(config-if-power4845-0)#power battery-test auto-test permit 60
huawei(config-if-power4845-0)#power environment temperature 68 -5 80 -20
huawei(config-if-power4845-0)#power temperature-off load-off-state forbid load-
off-temperature 70 battery-off-state permit battery-off-temperature 53
huawei(config-if-power4845-0)#power outside-digital 3 available-level low-level
name SPD digital-alarm 20
huawei(config-if-power4845-0)#power outside-digital 4 available-level high-level
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
1 Commissioning
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
108
