Huawei SmartAX MA5600T User Manual

ONU
Type
User Interface Supported ONU
Version
MA5698 Typical configuration:
l Pure broadband configurations: supports 4xGE
interfaces+16xFE electrical interfaces when two
EIUC boards are configured
l Leased line access configurations: supports 16xE1
interfaces when two E81A boards are configured
V800R313C00
MA5898 Typical configuration:
l Pure broadband configurations: supports 4xGE
interfaces+16xFE electrical interfaces when two
EIUC boards are configured
l Leased line access configurations: supports 16xE1
interfaces when two E81A boards are configured
V800R313C00
MA5612 For the bottom plate with POTS ports:
l Supports 2xGE electrical interfaces+6xFE electrical
interfaces+48xPOTS interfaces+(optional)1xRF
interface when two ASNB boards are configured.
l Supports 2xGE electrical interfaces+22xFE
electrical interfaces+16xPOTS interfaces+(optional)
1xRF interface when two EIUC boards are
configured.
l Supports 2xGE electrical interfaces+6xFE electrical
interfaces+16xE1/T1 interfaces+16xPOTS
interfaces+(optional)1xRF interface when two E81A
boards are configured.
For the bottom plate without POTS ports:
l Supports 2xGE electrical interfaces+6xFE electrical
interfaces+32xPOTS interfaces when two ASNB
boards are configured.
l Supports 2xGE electrical interfaces+22xFE
electrical interfaces when two EIUC boards are
configured.
l Supports 2xGE electrical interfaces+6xFE electrical
interfaces+16xE1/T1 interfaces when two E81A
boards are configured.
l V800R308C00
l V800R308C01
l V800R310C00
l V800R311C00
l V800R312C00
MA5628 There are two types of MA5628: integrated and box-
type. Both integrated MA5628 and box-type MA5628
provide:
l 4xE1/T1 interfaces
l 4xGE electrical interfaces
l V800R308C01
l V800R309C00
l V800R310C00
l V800R311C00
l V800R312C00
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 14 FTTM Configuration (Base Station Access)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1365
