Context
l When adding ONUs, you need to bind related profiles to the ONUs, including the DBA
profile, line profile, and alarm profile.
l An ONU can be added in two modes: offline addition and online confirmation. Select either
mode as required.
Data Planning
Table 14-5 Key data plan
Configurati
on Item
Data
DBA profile Profile ID: 20
Profile type: Type 3
Assured bandwidth: 100 Mbit/s
Maximum bandwidth: 120 Mbit/s
Line profile Profile ID: 10
T-CONT ID: 4
GEM port ID for management service of ONUs: 11
GEM Port ID for synchronization service of base stations: 12
GEM Port ID for OAM service of base stations: 13
GEM Port ID for voice and data services of base stations: 14
VLAN
(remark 1)
VLAN for management service of ONUs: 8
VLAN for base station access service:
l VLAN for synchronization service: 1000
l VLAN for OAM service: 1001
l VLAN for voice and data services: 1002
Networking
data
PON port: 0/3/1
ONU parameters:
l ONU ID: 1
l SN: 32303131B39FD641
Remark 1: Ethernet base stations have multiple services and different services require different
VLANs. The preceding table uses the synchronization service, OAM service, and voice and data
services as an example.
Procedure
Step 1 Configure GPON ONU profiles.
1. Configure a DBA profile.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
14 FTTM Configuration (Base Station Access)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1435
