Prerequisites
The SPUB board is in position and functions normally.
Data Plan
When OLTs are symmetrically connected to the packet switched network (PSN), the
configuration steps for OLT-A and OLT-B are the same, and only the configuration data varies
with the OLTs. The varied configuration data of OLT-A and OLT-B will be separately described
in this topic.
Table 14-7 Key data plan
Item Data
VLAN 1000
ONU E1 port
l Port ID: 0/1/0
l Port signaling mode: unstructured data transfer (UDT)
l Transmit clock of the port: system clock
IP address OLT-A:
l IP address of the VLAN interface: 10.0.0.10/24
l IP address of the loopback interface: 1.1.1.1/32
OLT-B:
l IP address of the VLAN interface: 10.0.0.20/24
l IP address of the loopback interface: 2.2.2.2/32
PW parameters The following parameters must be the same on the 2 OLTs.
l PW ID: 1
l PW type: TDM SAToP E1
l Control word: enabled
l PW load time: 125 μs
l Size of jitter buffer: 500 μs
l RTP header: enabled
Procedure
Step 1 Configure the TDM connection.
1. Configure the TDM virtual channel link (VCL) on the ONU.
On GPON port 0/3/1, create the TDM VCL for E1 port 0/1/0 of ONU 0.
NOTE
Each E81A board has 8 E1 ports. Port IDs 0 to 7 on board 0/1 correspond to ONT port IDs 1 to 8, port
IDs 0 to 7 on board 0/2 correspond to ONT port IDs 9 to 16, and so forth.
huawei(config-if-gpon-0/3)ont tdm-vcl 1 0 tdm-vcl-id 0 satop 1
huawei(config-if-gpon-0/3)quit
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
14 FTTM Configuration (Base Station Access)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1455
