Context
l When an ONU is added, related profiles need to be bound to the ONU, including the
dynamic bandwidth allocation (DBA) profile, line profile, and alarm profile.
l An ONU can be added in two modes: adding an ONU offline and confirming an ONU
online. Select either mode as required.
Data Plan
Table 14-8 Key data plan
Item Data
DBA profile DBA profile for management services: system default profile 1
DBA profile for private line services:
l Profile ID: 21
l Profile type: fixed bandwidth and minimum delay mode
l DBA bandwidth: 28928 kbit/s (assume that 4 E1 private lines are
connected to 1 ONU and each E1 private line is configured with a
bandwidth of 7232 kbit/s)
Line profile Profile ID: 11
T-CONT 1 is used for private line services and T-CONT 2 for management
services.
GEM port ID for management services: 11
GEM port ID for private line services: 13
Networking
data
PON port: 0/3/1
ONU parameters:
l ONU ID: 1
l SN: 32303131B39FD641
Management
VLAN and
management
IP address
On the OLT:
Management VLAN ID: 8
Management VLAN type: smart VLAN
Inband management IP address: 192.168.50.1/24
On the ONU:
Management VLAN ID: 8
Management VLAN type: smart VLAN
Inband management IP address: 192.168.50.2/24
Procedure
Step 1 Configure GPON ONU profiles.
1. Configure the DBA profile for private line services, enable bandwidth compensation, and
set the DBA bandwidth allocation mode of the GPON port to min-loop-delay.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
14 FTTM Configuration (Base Station Access)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1467
