with the OLTs. The varied configuration data of OLT-A and OLT-B will be separately described
in this topic.
Table 14-10 Key data plan
Item Data
VLAN 1000
E1 or SHDSL
port parameters
on the OLT
Slot for the EDTB board: 0/2
Port ID for E1 access: 0/2/0
Port ID for SHDSL access: 0/2/16
Transmit clock of the port: system clock
IP address OLT-A:
l IP address of the VLAN interface: 10.0.0.10/24
l IP address of the loopback interface: 1.1.1.1/32
OLT-B:
l IP address of the VLAN interface: 10.0.0.20/24
l IP address of the loopback interface: 2.2.2.2/32
PW parameters
l PW ID: 1
l PW type: TDM SAToP E1
l Control word: enabled
l PW load time: 125 μs
l Size of jitter buffer: 500 μs
l RTP header: enabled
Procedure
Step 1 Configure the TDM connection.
Both OLT-A and OLT-B adopt E1 or SHDSL access. The following shows how to configure
the TDM connection.
l For E1 access:
huawei(config)#interface edt 0/2
huawei(config-if-edt-0/2)#board workmode satop //The EDTB board must work in
the SAToP mode.
Success: Set the board workmode success
huawei(config-if-edt-0/2)#quit
huawei(config)#tdm-connect connectid 0 tdm pwe3-uplink 0/2 e1 0/2/0
l For SHDSL access:
huawei(config)#interface edt 0/2
huawei(config-if-edt-0/2)#board workmode satop
Success: Set the board workmode success
huawei(config-if-edt-0/2)#quit
huawei(config)#tdm-connect connectid 0 tdm pwe3-uplink 0/2 shdsl 0/2/16
Step 2 Configure the basic functions of multiprotocol label switching (MPLS).
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
14 FTTM Configuration (Base Station Access)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1481
