Concept Description
RX An optical receiver, which performs optical-to-electrical (O/E)
conversion for CATV and upstream backhaul signals.
TX An optical transmitter, which performs O/E conversion for received
CATV signals.
Combiner A component that combines multiple channels of analog signals into one
channel of signals on an RF port and then sends the signals to the
downstream optical TX.
GPON remote
extended frame
An OLT, deployed in a branch equipment room and working as a main
frame, connects to an MA5633 through a GPON cascading board. In
this manner, the MA5633 is no longer a standalone NE (no longer
allocated with an independent management IP address), but is managed
by the OLT. The MA5633 is regarded as a remote service board of the
OLT and has the same functions and features as those of the OLT.
GE remote
extended frame
An OLT, deployed in a branch equipment room and working as a main
frame, connects to an MA5633 through a GE cascading board. In this
manner, the MA5633 is no longer a standalone NE (no longer allocated
with an independent management IP address), but is managed by the
OLT. The MA5633 is regarded as a remote service board of the OLT
and has the same functions and features as those of the OLT.
NOTE
The difference between a GPON remote extended frame and a GE remote
extended frame lies in transmission media and network structure. Specifically,
the networking for the GPON remote extended frame is of the point-to-multipoint
(P2MP) structure and that for the GE remote extended frame is of the point-to-
point (P2P) structure.
MAN Network
Concept Description
Softswitch or IP
multimedia
subsystem (IMS)
Softswitch: core of the NGN network call and control, which supports
call and connection control for the services having high real-time
requirements. For the softswitch, services are separated from call control
and call control is separated from bearing. In addition, the softswitch
uses open service interface (API) and standard protocols, which
facilitates the development for new services and features.
IMS: uses Session Initiation Protocol (SIP) signaling as the call control
signaling. It provides voice, data, and multimedia services.
Broadband TV
(BTV) source
IPTV head end, a contents preparation platform in the IPTV system. It
receives signals, converts media formats, and manages media materials.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
15 OptiCable D-CMTS Configuration (MA5633 Working as
a Remote Extended Frame)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1521
