The OLT supports the adding of an automatically discovered GE remote extended frame.
This function does not require manual confirmation, thereby simplifying the remote
extended frame registration and adding flow.
huawei(config)#interface eth 0/3
huawei(config-if-eth-0/3)#network-role extend
This operation will reset the board. Are you sure to continue ? (y/n)[n]:y
huawei(config-if-eth-0/3)#quit
----End
Result
The remote extended frame is online.
After adding the remote extended frame, run the display frame info command to query the
remote extended frame status. Ensure that Online state is online and State is normal.
huawei(config)#display frame info 1
--------------------------------------------------------------------------
Type: MA5633
State: Normal
Desc: MA5633_1_extending_0/3/1
Hardware: MA5633
Extend type: ETH
Extending port: 0 /3 /1 //The cascading port on the OLT is 0/3/1.
Extended port: 1 /0 /0 //The ID of the remote extended frame is 1 and the uplink
port on the remote extended frame is 0/0/0.
Online state: Online
MAC address: 60DE-447D-8711
--------------------------------------------------------------------------
Follow-up Procedure
If the remote extended frame cannot be discovered, follow the troubleshooting suggestions listed
in the following table to rectify faults.
Possible Cause Troubleshooting Suggestion
The D-CMTS works as a
standalone NE and cannot
work as a remote extended
frame.
Replace the D-CMTS with the one that works as a remote
extended frame.
The D-CMTS management
policy is set to stand-alone on
the OLT.
Run the sysman centralized-mgmt primary command to
configure the D-CMTS management policy to extend-
frame.
The number of remote
extended frames on the OLT
has reached the threshold.
Run the frame delete command to delete a remote extended
frame that is no longer used from the OLT.
The working mode of the ports
on the remote extended frame
is not extend.
In Ethernet mode, run the network-role extend command
to set the working mode of the ports to extend.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
15 OptiCable D-CMTS Configuration (MA5633 Working as
a Remote Extended Frame)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1635
