Data Plan
Table 16-23 DHCP data plan for the OLT
Item Data
VLAN ID of the CM management S-VLAN: 100; type of the VLAN:
smart
DHCP server group
parameters
l IP address of the DHCP domain gateway for CMs:
10.10.224.1; domain name: docsis
l IP address of the DHCP domain gateway for media terminal
adapters (MTAs): 10.100.224.1; domain name: pktc
l IP address of the DHCP domain gateway for paid PCs:
10.100.187.1; domain name: default
l IP address of the DHCP domain gateway for overdue PCs:
10.100.8.1; domain name: default
l IP address of the DHCP domain gateway for set top boxes
(STB): 10.200.160.1; domain name: stb
Table 16-24 Data plan for the upper-layer devices of the OLT
Item IP Address
Layer 3 interfaces
connecting the router to
the OLT
l Forwarding DHCP and broadband packets: 11.11.11.11
l Forwarding CM management, VoD, and multicast packets:
11.11.12.11
IP addresses of DHCP
servers
l DHCP server assigning IP addresses to CMs and MTAs:
192.168.10.10-192.168.10.11
l DHCP server assigning IP addresses to PCs and STBs:
192.168.10.12-192.168.10.13
IP address of the TFTP
server
192.168.5.10-192.168.5.13
Procedure
Step 1 Set the IP addresses of Layer 3 VLAN interfaces.
huawei(config)#vlan 100 smart
huawei(config)#interface vlanif 100
huawei(config-if-vlanif100)#arp proxy enable
huawei(config-if-vlanif100)#ip address 10.10.224.1 255.255.255.0 description
docsis //Set the IP address of the DHCP domain gateway for CMs.
huawei(config-if-vlanif100)#ip address 10.100.224.1 255.255.255.0 sub description
pktc //Set the IP address of the DHCP domain gateway for MTAs.
huawei(config-if-vlanif100)#ip address 10.200.160.1 255.255.255.0 sub description
stb //Set the IP address of the DHCP domain gateway for STBs.
huawei(config-if-vlanif100)#ip address 10.100.187.1 255.255.255.0 sub description
default //Set the IP address of the DHCP domain gateway for paid PCs.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
16 OptiCable D-CMTS Configuration (MA5633 Working as
a Standalone NE)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1737
