Procedure
Step 1 Log in to and configure the ONU.
You can remote log in to the ONU from the OLT to perform the configuration. The user name
is root and the password is mduadmin.
Step 2 Create a service VLAN (S-VLAN).
NOTE
All home services use an S-VLAN and the S-VLAN is globally configured. If the S-VLAN has been configured
for other home services, use the S-VLAN in steps Step 1 and Step 2.
The S-VLAN is a user-side service VLAN between the optical line terminal (OLT) and the D-
CMTS. The OLT works in Layer 3 forwarding mode.
huawei(config)#vlan 100 smart
huawei(config)#port vlan 100 0/0 1
Step 3 Create a cable modem (CM) S-VLAN.
The CM S-VLAN identifies a CM service flow. After the CM S-VLAN is configured, the OLT
automatically creates a CM service flow when the CM goes online.
huawei(config)#cable service-vlan 100
Info: The new service VLAN will take effect after the CM is restarted, are you
sure to modify? (y/n)[n]:y
Step 4 Configure the Layer 3 interface for COPS connections.
huawei(config)#vlan 1000 smart
huawei(config)#interface vlanif 1000
huawei(config-if-vlanif1000)#ip address 192.168.60.3 24
huawei(config-if-vlanif1000)#quit
huawei(config)#port vlan 1000 0/0 1
Step 5 Configure a COPS connection.
The following configurations are used as an example to configure a COPS connection:
l COPS policy enforcement point (PEP) ID: IP address of the Layer 3 interface for the COPS
connection
l Transmit and receive buffer for TCP sockets: 12 KB
l Differentiated services code point (DSCP) priority of COPS packets: ef
huawei(config)#cops pepid 192.168.60.3
huawei(config)#cops tcp window 12
huawei(config)#cops ip dscp ef
Step 6 Configure PacketCable parameters.
PacketCable 1.x parameter settings are as follows:
l Embedded media terminal adapter (EMTA) creating a dynamic media stream: permitted
l Other parameters: default settings
huawei(config)#packetcable 1dotx enable
huawei(config)#packetcable authorize common-docsis-mta enable
huawei(config)#packetcable multimedia enable
----End
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
16 OptiCable D-CMTS Configuration (MA5633 Working as
a Standalone NE)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1763
