Figure 1-69 Set the password
NOTE
NE User, Context Engine ID, Priv Protocol and password, and Auth Protocol and
password must be the same as those configured on the MA5600T/MA5603T/
MA5608T. You can run the display snmp-agent usm-user command to query the device
user, data encryption protocol, and authentication protocol on the MA5600T/MA5603T/
MA5608T and run the display snmp-agent local-engineid command to query the
context engine ID on the MA5600T/MA5603T/MA5608T.
c. Click OK.
d. Select the added SNMP parameters. Click OK.
e. In the dialog box that is displayed, click Yes to test the set SNMP parameters.
f. The U2000 displays the Loading dialog box. After the testing is complete, click
OK.
3. Add a device.
a. In the Physical Root navigation tree on the Main Topology tab page, right-click
and choose New > NE from the shortcut menu.
b. In the dialog box that is displayed, choose Access NE > Access NE from the
main menu.
c. In the dialog box that is displayed, set the required parameters, as shown in
Figure 1-70.
IP address is 10.50.1.10, Device Name is huawei, SNMP Parameters is SNMP
V3:default.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 1 Commissioning
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
160
