Data plan of the ONU side
Item Data Memo
HSI service data plan
Traffic profile ID: 8
CIR: 4 Mbit/s
VLAN priority: 0
Downstream priority
policy: local-setting
-
User VLAN Untagged HGWs can send untagged packets or
packets with user VLAN tags.
User VLAN ID: 1, 2, 3...
Queue scheduling data plan
Queue scheduling Queue scheduling: strict
priority (SQ) mode
Priority mapping: mapped
into different queues based
on priorities
System default is adopted in this
example.
Service security data plan
System security Anti-DOS attack: disabled
Anti-ICMP attack: disabled
Anti-IP attack: disabled
System default is adopted in this
example.
User security Anti-MAC duplicate:
disabled
Anti-IP sproofing: disabled
System default is adopted in this
example.
PPPoE Service
security
RAIO Type: PITP P
RAIO Mode: common
PITP is recommended for PPPoE.
IPv4oE Service
security
RAIO Type: DHCP Option
82
RAIO Mode: common
DHCPv4 option and DHCPv6 option
are recommended for IPoE.
IPv6oE Service
security
RAIO Type: DHCPv6
Option
RAIO Mode: common
Voice service data plan
Media and signaling
upstream VLANs
200 H.248 protocol is adopted in this
example.
Media and signaling
upstream port
0/0/1
