Configure the mapping relationship between a GEM port and a VLAN. The service flow
of user VLAN 300 is mapped to GEM port 12 in the ONT line profile.
huawei(config)#ont-lineprofile gpon profile-name ftth
huawei(config-gpon-lineprofile-1)#gem mapping 12 2 vlan 300
huawei(config-gpon-lineprofile-1)#commit
huawei(config-gpon-lineprofile-1)#quit
Create a service VLAN and add an upstream port to it. Add upstream port 0/19/0 to VLAN
300.
huawei(config)#vlan 300 smart
huawei(config)#port vlan 300 0/19 0
Create service flows. Set the service VLAN to 300, GEM port ID to 12, and user VLAN
to 300, and use traffic profile ftth_voip.
huawei(config)#service-port vlan 300 gpon 0/1/0 ont 1 gemport 12 multi-service
user-vlan 300 inbound traffic-table name ftth_voip outbound traffic-table
name
ftth_voip
huawei(config)#service-port vlan 300 gpon 0/1/0 ont 2 gemport 12 multi-service
user-vlan 300 inbound traffic-table name ftth_voip outbound traffic-table
name
ftth_voip
2. Perform this step in the bridging ONT (double VLAN tags) scenario.
Table 19-12 Data plan
Scenario VLAN Plan VLAN Translation Policy
Bridging ONT Double VLAN tags
l SVLAN ID: 300
l SVLAN type: smart
l SVLAN attribute: stacking
l CVLAN ID: 3001
ONT: provides the VoIP
service and uses the same
CVLAN. A CVLAN identifies
a VoIP service.
OLT: implements VLAN
translation: C<->S+C.
Configure the mapping relationship between a GEM port and a VLAN. The service flow
of user VLAN 3001 is mapped to GEM port 12 in the ONT line profile.
huawei(config)#ont-lineprofile gpon profile-name ftth
huawei(config-gpon-lineprofile-1)#gem mapping 12 2 vlan 3001
huawei(config-gpon-lineprofile-1)#commit
huawei(config-gpon-lineprofile-1)#quit
Create a service VLAN and add an upstream port to it. Add upstream port 0/19/0 to VLAN
300.
huawei(config)#vlan 300 smart
huawei(config)#vlan attrib 300 stacking
huawei(config)#port vlan 300 0/19 0
Create service flows. Set the service VLAN to 300, GEM port ID to 12, and user VLAN
to 3001, and use traffic profile ftth_voip.
huawei(config)#service-port vlan 300 gpon 0/1/0 ont 1 gemport 12 multi-
service
user-vlan 3001 tag-transform default inbound traffic-table name ftth_voip
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
19 IPv6 Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1929
