NOTE
l In this example, the MA5600T/MA5603T/MA5608T works in the Layer 2 DHCP mode. Therefore, the
DHCP-related configurations are not required. If the MA5600T/MA5603T/MA5608T works in the Layer
3 DHCP mode, the DHCP-related configurations on the MA5600T/MA5603T/MA5608T are required. For
details, see Configuring DHCP Relay.
l For the details about the security of DHCP accounts, see Configuring Anti-Theft and Roaming of DHCPv4
User Accounts Using DHCP Option 82.
Assume that the RAIO mode is the user-defined mode, the CID is the access node name frame/
slot/port:vlanid, the RID is the label of the service port where the user is connected. To enable
the DHCP option 82 function with these parameters, do as follows:
huawei(config)#dhcp option82 enable
huawei(config)#raio-mode user-defined dhcp-option82
huawei(config)#raio-format dhcp-option82 cid anid frame/slot/port:vlanid
huawei(config)#raio-format dhcp-option82 rid splabel
Step 7 Save the data.
huawei(config)#save
----End
Verification
l Internet access verification on the user side:
– Step 1: After the PC NIC automatically obtains an IP address and a connection to the
Internet is set up, the user can access the Internet.
– Step 2: To download a file through FTP, open Windows Task Manager and then click
Networking to observe the link rate. Calculate the Internet access rate by the formula:
attainable Internet access rate = computer NIC rate/48 x 53 x 8. The calculated result
approximates to the planned 2048 kbit/s.
l DHCP emulation verification:
– Step 1: On the MA5600T/MA5603T/MA5608T run the dhcp simulation start
command to start DHCP emulation.
– Step 2: Run the display dhcp simulation command to query the DHCP emulation
status.
– After emulation is verified, run the dhcp simulation stop command to stop DHCP
emulation.
Configuration File
Configuration File for the ADSL access mode:
vlan 50 smart
vlan attrib 50 stacking
vlan forwarding 50 vlan-connect
port vlan 50 0/19 0
port vlan 50 0/19 1
link-aggregation 0/19 0 0/19 1 egress-ingress workmode lacp-static
interface adsl 0/2
deactivate 0
activate 0 template-index 1
alarm-config 0 1
quit
service-port 1 vlan 50 adsl 0/2/0 vpi 1 vci 39 inbound traffic-table index 5
outbound traffic-table index 5
service-port desc 1 description Vlanid:50/adsl/vpi:1vci:39/stacking
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
3 Configuring the DSLAM Services
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
265
