Item Data
Multicast protocol IGMPv3
Multicast program Dynamic generation
Program address range of ISP 1: 224.1.1.1-224.1.1.2
Program address range of ISP 2: 224.1.1.3-224.1.1.4
VDSL port attribute Working mode: PTM
Bound line profile and alarm profile: default profiles (profile
ID: 1)
Port connected to user 1: 0/2/1
Port connected to user 2: 0/4/1
Multicast user Multicast user log recording: enabled
Procedure
Step 1 Configure multicast VLANs and programs.
Configure smart VLAN 10 as the multicast domain of ISP 1, and smart VLAN 20 as the multicast
domain of ISP 2.
1. Configure the protocol, multicast upstream port, and program list of multicast VLAN 10.
Configure multicast VLAN 10 with the dynamic program generation mode, and specify
the range of the IP addresses of the programs that can be requested by the users in multicast
VLAN 10 as 224.1.1.1 to 224.1.1.2. Multicast VLAN 10 adopts IGMP proxy, IGMP v3
(system default value), and multicast upstream port 0/19/0.
NOTICE
The multicast program configuration mode can be changed only when igmp match
mode is set to off. However, setting igmp match mode to off will cause users to go offline.
Therefore, it is recommended that the program configuration mode be planned beforehand.
huawei(config)#vlan 10 smart
huawei(config)#multicast-vlan 10
huawei(config-mvlan10)#igmp match mode disable
huawei(config-mvlan10)#igmp match group ip 224.1.1.1 to-ip 224.1.1.2
huawei(config-mvlan10)#igmp uplink-port 0/19/0
huawei(config-mvlan10)#igmp mode proxy
huawei(config-mvlan10)#quit
2. Configure the protocol, multicast upstream port, and program list of multicast VLAN 20.
Configure multicast VLAN 20 with the dynamic program generation mode, and specify
the range of the IP addresses of the programs that can be requested by the users in multicast
VLAN 10 as 224.1.1.3 to 224.1.1.4. Multicast VLAN 20 adopts IGMP proxy, IGMP v3
(system default value), and multicast upstream port 0/19/0.
huawei(config)#vlan 20 smart
huawei(config)#multicast-vlan 20
huawei(config-mvlan20)#igmp match mode disable
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
3 Configuring the DSLAM Services
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
299
