Item Data
Phone number 12345601, 12345602
Automatic
deactivation
Disabled
Activation
mode
Stable activation
Procedure
Step 1 Configure the working mode of the ISDN BRA port.
In the BRA port mode, configure the working mode of the ISDN BRA port to P2P, configure
the activation mode to stable activation, and disable automatic activation.
huawei(config)#braport
huawei(config-braport)#braport attribute set 0/2/0 workmode p2p activemode stable-
active autodeactive disable
huawei(config-braport)#braport attribute set 0/3/0 workmode p2p activemode stable-
active autodeactive disable
huawei(config-braport)#quit
Step 2 Add an IUA link set and IUA links.
In the SIGTRAN mode, configure the SIGTRAN protocol stack. Add an IUA link set, and then
add IUA links.
huawei(config)#sigtran
huawei(config-sigtran)#iua-linkset add 1 mgid 0 jointly-work enable trafficmode
override
iid-map 2 pendingtime cs-mode client
huawei(config-sigtran)#iua-link add 15 1 1401 10.13.4.116 1400 10.14.1.2
jointly-work-with primary-mgc priority 3
huawei(config-sigtran)#quit
NOTE
All the ISDN call control messages are sent from the IUA link to the softswitch, whereas the system uses
the bearer control messages to communicate with the softswitch through H.248.
Step 3 Configure the ISDN BRA user data.
huawei(config)#esl user
huawei(config-esl-user)#mgbrauser add 0/2/0 0 1 interfaceid 8 terminalid 100 telno
12345601
huawei(config-esl-user)#mgbrauser add 0/3/0 0 1 interfaceid 9 terminalid 110 telno
12345602
huawei(config-esl-user)#quit
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
3 Configuring the DSLAM Services
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
331
