Table 3-14 Data plan for configuring TDM SHDSL for carrying the PRA service
Item Data
Clock source E1 line clock on port 0/3/0
SHDSL port Port ID: 0/3/16
PRA user interface data MGID: 0
IUA link set ID: 0
Terminal ID: 0
Phone number: 12345600
Prerequisite
l The H802EDTB board must be in position and must work in the normal state.
l The MA5600T/MA5603T/MA5608T must use the SIP protocol to communicate with the
IMS in the normao state.
l An SHDSL modem must be correctly connected and the SHDSL port(s) must be activated.
Procedure
Step 1 (Optional) Configure the working mode of the board
Configure the working mode of the board to voice.
NOTE
The working sub-mode of the board can be configured only when the working mode of the board is configured
to voice. By default, the working mode of the board is voice.
huawei(config)#interface edt 0/3
huawei(config-edt-0/3)#board workmode voice
Step 2 (Optional) Configure the working sub-mode of the board.
According to the service requirement, configure the working sub-mode of the board to service
mode. By default, the working sub-mode of the board is service.
huawei(config-edt-0/3)#runmode service
Step 3 (Optional) Configure the clock source of the board.
Configure the E1 line clock on port 0/3/0 as the clock source.
NOTE
You can select the line clock or system clock as the clock source of the board according to your requirements.
By default, the system clock is used as the clock source.
huawei(config-edt-0/3)#set clockmode line 0
Step 4 Configure the attributes of the SHDSL port.
Configure the signaling mode of SHDSL port 0/3/16 to CCS. PRA D channel signaling is
transmitted in timeslot 16 and timeslot 0 is used for frame synchronization.
huawei(config-edt-0/3)#shdslport signal 16 CCS
huawei(config-edt-0/3)#quit
Step 5 Configure a PRA user.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
3 Configuring the DSLAM Services
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
350
