Item service Type Remarks
UBR VBR CBR
Traffic
Profile
l CAR:
OFF
l Color
policy:
cos-
remark
l Downst
ream
priority
policy:
tag-in-
packag
e
l CAR:
OFF
l Color
policy:
cos-
remark
l Downst
ream
priority
policy:
tag-in-
packag
e
l CAR: OFF
l Color policy:
cos-remark
l Downstream
priority
policy: tag-
in-package
The traffic profile does no limit the
rate. Instead the rate is limited
using PWs.
Procedure
Step 1 Configure a VLAN and add an upstream port to the VLAN.
Create upstream VLAN 300 and add upstream port 0/19/1 to VLAN 300.
huawei(config)#vlan 300 standard
huawei(config)#port vlan 300 0/19 1
Step 2 Enable MPLS.
1. Configure the IP address of the loopback interface.
Configure the IP address of loopback interface 0 to 5.5.5.5/32.
huawei(config)#interface loopback 0
huawei(config-if-loopback0)#ip address 5.5.5.5 32
huawei(config-if-loopback0)#quit
2. Configure the LSR ID of the MPLS and enable global MPLS function and Layer 2 VPN.
huawei(config)#mpls lsr-id 5.5.5.5
huawei(config)#mpls
huawei(config-mpls)#quit
huawei(config)#mpls l2vpn
3. Enable the MPLS function for VLAN 300, configure the IP address of the VLAN interface
300, and enable the MPLS function for it.
huawei(config)#mpls vlan 300
huawei(config)#interface vlanif 300
huawei(config-if-vlanif300)#ip address 192.168.1.20 24
huawei(config-if-vlanif300)#mpls
huawei(config-if-vlanif300)#quit
Step 3 Configure a route.
PWE3 has no special requirement for the routing policy. Either a static route or an OSPF dynamic
route can be configured. Because OSPF supports MPLS RSVP-TE extension, an OSPF dynamic
route is recommended.
huawei(config)#ospf 1
huawei(config-ospf-1)#area 200
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
4 Configuration Example of the Private Line Service
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
404
