Commit the configuration and quit the tunnel configuration.
huawei(config-if-tunnel20)#mpls te commit
huawei(config-if-tunnel20)#quit
Step 5 Configure the tunnel policy.
Configure the policy name to atmpw-plcy.
huawei(config)#tunnel-policy atmpw-plcy
Info: New tunnel-policy is configured.
huawei(config-tunnel-policy-atmpw-plcy)#tunnel binding destination 7.7.7.7 te
tunnel 20
huawei(config-tunnel-policy-atmpw-plcy)#quit
Step 6 Configure the PW parameters.
NOTE
Take the configuration of PW 20 for example. To configure the PW 21 and PW 22 based on the data plan using
the same steps.
1. Configure the PW ID to 20.
huawei(config)#pw-para 20
2. Configure the LSR ID of the peer PWE3 gateway in the PW. Configure the LSR ID of the
PWE3 gateway to 7.7.7.7.
huawei(config-pw-para-20)#peer-address 7.7.7.7
3. Configure the PW type to ATM NTo1 VCC.
huawei(config-pw-para-20)#pw-type atm nto1 vcc
4. Configure the PW to support the control word.
huawei(config-pw-para-20)#control-word
5. (Optional) Set the maximum number of concatenated ATM cells to 4.
huawei(config-pw-para-1)#max-atm-cells 4
6. (Optional) Set the maximum encapsulation delay of ATM cells to 10 ms.
huawei(config-pw-para-1)#max-encapcell-delay 10
7. Configure the tunnel policy used by the PW.
Configure the tunnel policy name to atmpw-plcy.
huawei(config-pw-para-20)#tnl-policy atmpw-plcy huawei(config-pw-para-20)#quit
Step 7 Create an ATM access service stream.
ATM cells must be encapsulated into ATM over Ethernet (AOE) packets before being carried
by PWs. That is, create an ATM service stream.
l Create AOE service streams in batches for UBR services.
The service board is in slot 0/2, VPI/VCI is 0/35, and the traffic profile for the upstream and
downstream directions is 20.
huawei(config)#multi-service-port vlan aoe board 2 vpi 0 vci 35 inbound
traffic-table index 20 outbound traffic-table index 20
l Create AOE service streams in batches for VBR services.
The service board is in slot 0/3, VPI/VCI is 0/35, and the traffic profile for the upstream and
downstream directions is 21.
huawei(config)#multi-service-port vlan aoe board 3 vpi 0 vci 35 inbound
traffic-table index 21 outbound traffic-table index 21
l Create AOE service streams in batches for CBR services.
The service board is in slot 0/4, VPI/VCI is 0/35, and the traffic profile for the upstream and
downstream directions is 22.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
4 Configuration Example of the Private Line Service
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
412
