huawei(config-voip)#ip address signaling 10.176.6.33
huawei(config-voip)#quit
4. Configure the MG interface.
Add an MG interface.
huawei(config)#interface h248 0
Are you sure to add MG interface? (y/n)[n]:y
Configure the MG interface attributes.
huawei(config-if-h248-0)#if-h248 attribute mgip 10.176.6.33 mgport 2944 code
text
transfer udp primary-mgc-ip1 10.30.80.65 primary-mgc-port 2944 mg-media-ip1
10.176.6.33
Configure the software parameters of the MG interface (in this example, only parameter
20 is configured, and other parameters use the default values).
huawei(config-if-h248-0)#mg-software parameter 20 2
5. Reset the MG interface.
NOTE
After configuring the MG interface, you need to reset the interface to validate the configuration.
huawei(config-if-h248-0)#reset coldstart
Are you sure to reset MG interface?(y/n)[n]:y
huawei(config-if-h248-0)#quit
6. Configure the data of PSTN user.
huawei(config)#esl user
huawei(config-esl-user)#mgpstnuser batadd 0/3/0 0/3/31 0 terminalid 0 telno
88660032
huawei(config-esl-user)#quit
Step 12 Configure the stacking multi-ISPs wholesale service.
ISP1 provides users of ports 0/2/0 to 0/2/10 on board with the multi-ISP wholesale service. ISP2
provides users of ports 11-20 to with the multi-ISP wholesale service. ISP3 provides users of
port 21-30 with the multi-ISP wholesale service.
1. Create a VLAN and set the attribute as stacking.
huawei(config)#vlan 60 to 62 smart
huawei(config)#vlan attrib 60 to 62 stacking
2. Add the upstream port.
huawei(config)#port vlan 60 to 62 0/19 0-1
3. Add the service port.
huawei(config)#multi-service-port vlan 60 port 0/2 0-10 vpi 0 vci 35 rx-cttr 6
tx-cttr 6
huawei(config)#multi-service-port vlan 61 port 0/2 11-20 vpi 0 vci 35 rx-cttr
6 tx-cttr 6
huawei(config)#multi-service-port vlan 62 port 0/2 21-30 vpi 0 vci 35 rx-cttr
6 tx-cttr 6
4. Configure the inner label.
huawei(config)#stacking label vlan 60 baselabel 111
huawei(config)#stacking label vlan 61 baselabel 112
huawei(config)#stacking label vlan 62 baselabel 113
Step 13 Configure the triple play service.
After the configuration, the following results should be achieved: Users of ports 0/2/16 can watch
the programs stored on servers 224.1.1.1 and 224.1.1.2, and can preview the programs stored
on server 224.1.1.3.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
5 Configuration Example of MSTP Subtending Network
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
462
