4. Configure the MG interface.
Add an MG interface.
huawei(config)#interface h248 0
Are you sure to add MG interface? (y/n)[n]:y
Configure the MG interface attributes.
huawei(config-if-h248-0)#if-h248 attribute mgip 10.176.6.33 mgport 2944 code
text
transfer udp primary-mgc-ip1 10.30.80.65 primary-mgc-port 2944 mg-media-ip1
10.176.6.33
Configure the software parameters of the MG interface (in this example, only parameter
20 is configured, and other parameters use the default values).
huawei(config-if-h248-0)#mg-software parameter 20 2
5. Reset the MG interface.
NOTE
After configuring the MG interface, you need to reset the interface to validate the configuration.
huawei(config-if-h248-0)#reset coldstart
Are you sure to reset MG interface?(y/n)[n]:y
huawei(config-if-h248-0)#quit
6. Configure the data of PSTN user.
huawei(config)#esl user
huawei(config-esl-user)#mgpstnuser batadd 0/3/0 0/3/31 0 terminalid 0 telno
88660000
huawei(config-esl-user)#quit
Step 11 Configure the multicast service.
After the configuration, the following results should be achieved:
l Users of port 0/2/2 must be authenticated, and have rights to watch two programs and to
preview one program.
l Users of port 0/2/3 do not need authenticating.
1. Configure the xDSL.
In this example, it is unnecessary to configure the xDSL. The default line profile (profile
1002) is used.
2. Configure the VLAN.
l Create a smart VLAN.
huawei(config)#vlan 100 smart
l Set the VLAN upstream port.
huawei(config)#port vlan 100 0/19 0
l Configure the native VLAN.
huawei(config)#interface giu 0/19
huawei(config-if-giu-0/19)#native-vlan 0 vlan 100
huawei(config-if-giu-0/19)#quit
l Create a traffic profile.
huawei(config)#traffic table ip index 8 cir off priority 5 priority-policy
local-Setting
l Add ADSL2+ ports 2 and port 3 to VLAN 100.
huawei(config)#service-port vlan 100 adsl 0/2/2 vpi 0 vci 35 rx-cttr 8
tx-cttr 8
huawei(config)#service-port vlan 100 adsl 0/2/3 vpi 0 vci 35 rx-cttr 8
tx-cttr 8
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
5 Configuration Example of MSTP Subtending Network
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
480
