Table 6-3 Key data plan
Confi
gurati
on
Item
Data Remarks Requirement on SPE1
and SPE2
MPLS
l LSR ID:
10.10.10.10
l VLAN: 4001
MPLS must be enabled at
three layers.
l MPLS must be enabled
globally.
l MPLS must be enabled
for VLAN.
l MPLS must be enabled at
VLAN interfaces.
The LSR ID must be unique
on the entire network and
MPLS must be enabled.
LDP
l MPLS LDP is
enabled.
l Split horizon is
enabled.
MPLS LDP must be enabled
at two layers.
l MPLS LDP must be
enabled globally.
l MPLS LDP must be
enabled at VLAN
interfaces.
MPLS LDP is enabled. The
remote LDP session to the
MA5600T/MA5603T/
MA5608T is configured on
SPE1 and SPE2.
Routin
g
protoc
ol
The Open Shortest
Path First (OSPF)
protocol is used.
Ensure that the Layer 3
interfaces on the MA5600T/
MA5603T/MA5608T and
those on SPE1 and SPE2 can
ping each other.
Layer 3 interfaces and routes
are configured on SPE1 and
SPE2. Ensure that the Layer
3 interfaces and loopback
interfaces on SPE1 and SPE2
and those on the MA5600T/
MA5603T/MA5608T can
ping each other.
VPLS
PW
l PW ID: 1 and 2
l Service type:
vpls
l Encapsulation
type: ethernet
tagged
l The control
word is enabled.
L2VPN must be enabled.
On the MA5600T/
MA5603T/MA5608T, PW1
and PW2 are created for
SPE1 and SPE2 respectively.
The LDP VPLS is supported.
VPLS PWs to the MA5600T/
MA5603T/MA5608T are
configured on SPE1 and
SPE2, and attributes of PWs
are consistent with those on
the MA5600T/MA5603T/
MA5608T.
VSI
l PW1 and PW2
are bound to
VSI.
l Multicast
service VLAN
100 is bound to
VSI.
Multicast VLAN is bound
through VSI to map VLAN to
the VPLS domain, so that
multicast service packets can
be broadcast in the VPLS
domain.
VSI is configured on SPE1
and SPE2 and the VSI ID
must bind the corresponding
PW.
